Description

Sensing type	Diffuse reflective type
Sensing distance	2m
Sensing target	Opaque, Translucent material
Light source	Infrared LED(850nm)
Response time	Max. 1ms
Power voltage	12-24VDC ±10%(ripple P-P: max. 10%)
Current consumption	Max. 15mA
Sensitivity adjustment	Sensitivity adjuster
Operation mode	Dark ON
Control output	PNP open collector
Connection type	Cable type(Ø3, 2m)
Environment_Ambient illumination	Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature	-25 to 55℃, storage: -25 to 70℃
Protection structure	IP64
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Hysteresis(distance)	Max. 20% at sensing distance
Material	Case: Acrylonitrile butadiene styrene, Sensing part: Polycarbonate, Indicator: Polycarbonate, Adjuster: IXEF
Accessories	Adjuster driver
Weight	Approx. 50g

Product form

Sensing type Diffuse reflective type Sensing distance 2m Sensing target Opaque, Translucent material Light source Infrared LED(850nm) Response time Max.... Read more

SKU: BA2M-DDTD-P

$36.49 Excl. VAT

Ships within 5–10 business days

Ships from South Korea

Export packing available

Worldwide shipping

Secure payments Paypal

Need a bulk or multi-brand quotation?

Get quotes for 10+ items across SMC, NSK, LS Electric and 900+
Korean brands at ProSource MRO — operated by the same team.

Request a Bulk Quote →

Description

Sensing type	Diffuse reflective type
Sensing distance	2m
Sensing target	Opaque, Translucent material
Light source	Infrared LED(850nm)
Response time	Max. 1ms
Power voltage	12-24VDC ±10%(ripple P-P: max. 10%)
Current consumption	Max. 15mA
Sensitivity adjustment	Sensitivity adjuster
Operation mode	Dark ON
Control output	PNP open collector
Connection type	Cable type(Ø3, 2m)
Environment_Ambient illumination	Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature	-25 to 55℃, storage: -25 to 70℃
Protection structure	IP64
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Hysteresis(distance)	Max. 20% at sensing distance
Material	Case: Acrylonitrile butadiene styrene, Sensing part: Polycarbonate, Indicator: Polycarbonate, Adjuster: IXEF
Accessories	Adjuster driver
Weight	Approx. 50g

Reviews

Name: Autonics Photoelectric Sensor, Photoelectric Type BA2M-DDTD-P
Brand: Autonics
SKU: BA2M-DDTD-P
Price: 36.49 USD
Availability: InStock

Autonics Photoelectric Sensor, Photoelectric Type BA2M-DDTD-P
