Power voltage
|
12 - 24 V d.c. ±10 % (Ripple max. 10 %)
|
|
Control output
|
NPN or PNP open collector output
▪Load current - max. 100 mA (26.4 V d.c. standard)
▪Residual voltage - NPN: max. 1 V, PNP : max. 1 V
|
|
Operation mode
|
Light ON / Dark ON switch
|
|
Response time
|
1 ms or less
|
|
Insulation Resistance
|
More than 20 MΩ (500 V d.c. mega)
|
|
Noise immunity
|
Square wave noise by noise simulator (pulse width 1 μs) ± 240 V
|
|
Dielectric strength
|
1,000 V a.c. (50/60 Hz for 1 minute)
|
|
Vibration resistance
|
10 - 55 Hz, Double amplitude : 1.5 mm, X·Y·Z 2 in each direction for 2 hours
|
|
Shock resistance
|
500 m/s², X·Y·Z each direction 3 times
|
|
Ambient illumination
|
▪Sunlight : max. 11,000 lx / Incandescent : max 3,000 lx
|
|
Ambient temperature
|
▪During operation : -25 ~ +55 ℃, During storage : -40 ~ +70 ℃ (Without condensation or icing)
|
|
Ambient humidity
|
▪35 ~ 85 % RH (Without condensation)
|
|
Degree of protection
|
IP65 (IEC standard)
|
|
Certification
|
 |
|
Material
|
Case
|
PBT GF30 %
|
|
Display
|
PC
|
|
Lens
|
PC
|
