Description
The Schneider Electric Acti9 iOF A9A26914 is an auxiliary contact that signals the open/closed (ON/OFF) state of the protective device it is fitted to. Its low-level 2 mA–100 mA contact rating makes it compatible with PLC and I/O module inputs. It clips directly onto the left side of the circuit breaker with no tools, and devices can be daisy-chained to monitor up to 100 protective devices (permanently closed).
Specifications
| Model |
A9A26914 |
| Range |
Acti9 A9A |
| Function |
iOF — ON/OFF indication auxiliary contact |
| Contact configuration |
1 C/O (changeover) |
| Rated current |
2 mA to 100 mA (low-level) |
| Rated voltage |
24–250 VAC / 24–220 VDC |
| Connection |
Bottom connection |
| Mounting |
Clips onto the left side of the circuit breaker |
| Compatible with |
Acti9 iC60, iID, iC40, iSW-NA |
| Daisy chain |
Monitors up to 100 protective devices (permanently closed) |
Note
This is the low-level version for PLC/I/O signaling. For standard auxiliary circuits (100 mA to 6 A), choose A9A26924.
