Description
SMC CDQ2B40TF-10SMZ-L — CQ2-Z Series Compact Cylinder, Single Acting, Single Rod. This code specifies 40mm bore, 10mm stroke, single acting.
Specification — CDQ2B40TF-10SMZ-L
| Bore |
40mm |
| Stroke |
10mm |
| Action |
Single acting |
About the SMC CQ2-Z series
- A space-saving cylinder designed with a thin overall length to realize compact equipment
- Small auto switches can be attached to 4 surfaces (2 surfaces for ø12 to ø25).
- There is no protruding auto switch.
- Light weight: reduced by 5~13% (compared to the previous CQ2)
- Newly added support bracket for double clevis and compact foot type bracket
- Enclosed installation bolt and set the part number for rod end bracket attachment (reducing the trouble of ordering separately)
Supply from Korea
Genuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.
