Name: SMC CQS Series, Compact Type Cylinder, Double Acting, Single Rod, CQSB16-10D
Brand: SMC
SKU: CQSB16-10D
Price: 17.8 USD
Availability: InStock

SMC CQS Series, Compact Type Cylinder, Double Acting, Single Rod, CQSB16-10D

VendorSMC

Description

OVERVIEW

Square type with shorter overall length, auto switch can be mounted on 3 or 4 sides
Compact cylinder that does not protrude from the main body when auto switch is attached.
Newly added support bracket for double clevis and compact foot type bracket.
With auto switch (CDQS series: CDQS, CDQSW, CDQSK, CDQSKW, CDQS S)

Specification item	model symbol	Specification information
built-in magnet	-	No built-in magnet
installation support	B	Basic type
tube inner diameter	16	tube inner diameter 16mm
cylinder stroke	10	cylinder stroke 10mm
dual stroke mark	-	No dual stroke mark
cylinder stroke 2	-	Cylinder stroke 2 None
option	-	Standard (rod end female thread)
auto switch	-	Without auto switch
Auto switch additional symbol	-	2 with or without
Custom made specifications	-	standard

Specification — CQSB16-10D

Magnet	No built-in magnet
Mounting	Basic
Bore	16mm
Stroke	10mm
Auto switch	Without auto switch
Port size	M5X0.8
Fluid	Air
Action	Double acting
Port thread	M
Min. operating pressure	0.07 MPa
Max. operating pressure	1.0 MPa
Proof pressure	1.5 MPa
Lubrication	Non-lube
Fluid temp. min	-10 °C
Fluid temp. max	70 °C
Ambient temp. min	-10 °C
Weight	47 g

Specification values above are for model code CQSB16-10D as published by SMC. A change of one character in the suffix gives a different part, so order by the full code.
