Name: SMC CQS Series, Compact Type Cylinder, Double Acting, Single Rod, CQSB20-20D
Brand: SMC
SKU: CQSB20-20D
Price: 22.98 USD
Availability: InStock

SMC CQS Series, Compact Type Cylinder, Double Acting, Single Rod, CQSB20-20D

VendorSMC

Description

OVERVIEW

Square type with shorter overall length, auto switch can be mounted on 3 or 4 sides
Compact cylinder that does not protrude from the main body when auto switch is attached.
Newly added support bracket for double clevis and compact foot type bracket.
With auto switch (CDQS series: CDQS, CDQSW, CDQSK, CDQSKW, CDQS S)

Specification item	model symbol	Specification information
built-in magnet	-	No built-in magnet
installation support	B	Basic type
tube inner diameter	20	tube inner diameter 20mm
cylinder stroke	20	cylinder stroke 20mm
dual stroke mark	-	No dual stroke mark
cylinder stroke 2	-	Cylinder stroke 2 None
option	-	Standard (rod end female thread)
auto switch	-	Without auto switch
Auto switch additional symbol	-	2 with or without
Custom made specifications	-	standard

Specification — CQSB20-20D

Magnet	No built-in magnet
Mounting	Basic
Bore	20mm
Stroke	20mm
Auto switch	Without auto switch
Port size	M5X0.8
Fluid	Air
Action	Double acting
Port thread	M
Min. operating pressure	0.05 MPa
Max. operating pressure	1.0 MPa
Proof pressure	1.5 MPa
Lubrication	Non-lube
Fluid temp. min	-10 °C
Fluid temp. max	70 °C
Ambient temp. min	-10 °C
Weight	101 g

Specification values above are for model code CQSB20-20D as published by SMC. A change of one character in the suffix gives a different part, so order by the full code.

Product form

OVERVIEW Square type with shorter overall length, auto switch can be mounted on 3 or 4 sides Compact cylinder that... Read more

SKU: CQSB20-20D

$22.98 Excl. VAT

Ships within 5–10 business days

Ships from South Korea

Export packing available

Worldwide shipping

Secure payments Paypal

Description

OVERVIEW

Square type with shorter overall length, auto switch can be mounted on 3 or 4 sides
Compact cylinder that does not protrude from the main body when auto switch is attached.
Newly added support bracket for double clevis and compact foot type bracket.
With auto switch (CDQS series: CDQS, CDQSW, CDQSK, CDQSKW, CDQS S)

Specification item	model symbol	Specification information
built-in magnet	-	No built-in magnet
installation support	B	Basic type
tube inner diameter	20	tube inner diameter 20mm
cylinder stroke	20	cylinder stroke 20mm
dual stroke mark	-	No dual stroke mark
cylinder stroke 2	-	Cylinder stroke 2 None
option	-	Standard (rod end female thread)
auto switch	-	Without auto switch
Auto switch additional symbol	-	2 with or without
Custom made specifications	-	standard

Specification — CQSB20-20D

Magnet	No built-in magnet
Mounting	Basic
Bore	20mm
Stroke	20mm
Auto switch	Without auto switch
Port size	M5X0.8
Fluid	Air
Action	Double acting
Port thread	M
Min. operating pressure	0.05 MPa
Max. operating pressure	1.0 MPa
Proof pressure	1.5 MPa
Lubrication	Non-lube
Fluid temp. min	-10 °C
Fluid temp. max	70 °C
Ambient temp. min	-10 °C
Weight	101 g

Specification values above are for model code CQSB20-20D as published by SMC. A change of one character in the suffix gives a different part, so order by the full code.
