SMC MSQ Series Rotary Table Rack and Pinion Type, High Precision, MSQA50L2-M9NM

Description

OVERVIEW



  • integration of table and rotary actuator
  • Attachment of angle adjustment mechanism
  • Easy centering during load installation and body installation
  • Available with built-in shock absorber and external absorber



Configuration Options




1 Size 1,2,3,7
2 Nominal size (Torque) 1 MSUA 1
3 Connection port location Nil End Port
E Front Port
4 Auto switch Nil Without auto switch (built-in magnet)

Specification — MSQA50L2-M9NM

Weight 2,090 g

Specification values above are for model code MSQA50L2-M9NM as published by SMC. A change of one character in the suffix gives a different part, so order by the full code.

Product form

OVERVIEW integration of table and rotary actuator Attachment of angle adjustment mechanism Easy centering during load installation and body installation... Read more

SKU: MSQA50L2-M9NM

$876.68 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal
