| Sensing distance |
600 to 8000 mm |
| Blind zone |
0 to 590 mm |
| Foreground suppression |
600 to 1800 mm |
| Max. setting zone |
8000 mm |
| Transducer frequency |
80 kHz |
| Switching frequency |
≥ 3 Hz |
| Response time |
≤ 300 ms |
| Hysteresis |
100mm |
| Standard sensing target |
500 × 500 mm |
| Resolution |
≥ 0.180 mm |
| Power voltage |
12 - 30 VDC (ripple P-P: ≤ 10 %) |
| Current consumption |
≤ 80 mA (no load) |
| Digital output |
Push-pull |
| Analog output |
[voltage output] DC 0 - 10 V, [current output] DC 4 - 20 mA |
| Protection circuit |
Surge protection circuit, output short over current protection circuit, reverse polarity protection |
| Insulation resistance |
≥ 50 MΩ (500 VDC megger) |
| Dielectric strength |
Between the charging part and the case: 1,000 VAC~ 50 / 60 Hz for 1 min |
| Vibration |
1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours |
| Shock |
500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times |
| Ambient temperature |
-25 to 70 ℃, storage: -40 to 85 ℃ (no freezing or condensation) |
| Protection structure |
IP66, IP67 (IEC standard) |
| Connection |
Connector models |
| Connector type |
M12 5-pin plug connector |
| Material |
Case: mount - SUS316L, body - PC, transducer: polyurethane foam, epoxy resin with glass |
| Unit weight (packaged weight) |
≈210g(≈330g) |
