| Sensing type |
Retroreflective type(standard type) |
| Sensing distance |
5m(MS-2) |
| Sensing target |
Opaque material of min. Ø60mm |
| Light source |
Infrared LED(940nm) |
| Response time |
Max. 20ms |
| Power voltage |
24-240VAC~ ±10% 50/60Hz, 24-240VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 4VA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by switch) |
| Control output |
Relay |
| Connection type |
Cable type(Ø5, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-20 to 65℃, storage: -25 to 70℃ |
| Protection structure |
IP50 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case, Case cover: Heat resistant Acrylonitrile butadiene styrene,
Sensing part: Polycarbonate(with polarizing filter: polymethyl methacrylate),
Bracket: Steel Plate cold commercial, Bolt: steel chromium molybdenum,
Nut: steel chromium molybden |
| Accessories_Individual |
Reflector(MS-2) |
| Accessories_Common |
Adjuster driver, Fixing bracket, Bolts, Nuts |
| Weight |
Approx. 208g |
