| Power voltage |
Using power from the amplifier unit. |
| Power consumption |
Max. 2.3W |
| Communication function |
RS-232C, RS-485 |
| Communication speed |
9600, 19200, 38400, 115200bps (default) |
| Indication |
4 LED status indicators |
| Function |
• Real-time monitoring
• Executes every BD-Series feature and sets parameter by external device (Master) |
| Environment_Ambient temperature |
-10 to 50℃, storage: -15 to 60℃ |
| Environment_Ambient humidity |
Under 85%RH, storage: under 85%RH |
| Vibration |
1.5mm amplitude at frequency of 10 to 50Hzin each X, Y, Z direction for 2 hours |
| Shock |
300m/s² (approx. 30G) in each X, Y, Z direction for 3 times |
| Protection structure |
IP40 (IEC Standards) |
| Material |
Case: Polycarbonate |
| Accessories |
Side connector, Connector for RS485 |
| Sold separately |
Communication converter (SCM-38I, SCM-US48I, SCM-WF48) Approval Weight※ |
| Weight |
Approx. 91g (approx. 49g) |
