| Display |
Status indicator × 5 |
| Communication |
EtherCAT |
| Power voltage |
10 - 30 VDC (ripple P-P: ≤ 10 %) |
| Power supply |
Power connector (3-pin) |
| Max. expansion Amp. units |
≤ 16 units |
| Current consumption |
≤ 300 mA (10 VDC), ≤ 200 mA (30 VDC) |
| Amp. allowable current |
Max. 2A |
| Amp. connection |
Via side connector |
| Unit weight (packaged weight) |
≈ 81 g (≈ 125 g) |
| Protection circuit |
Reverse power protection circuit, surge protection circuit |
| Insulation resistance |
≥ 20 MΩ (500 VDC megger) |
| Dielectric strength |
Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute |
| Vibration |
1.5 mm double amplitude at frequency of 10 to 55 Hz in each X, Y, Z direction for 2 hours |
| Shock |
500m/s²(approx. 50G) in each X, Y, Z direction for 3 times |
| Environment_Ambient temperature |
-10 to 50℃, storage: -20 to 70℃ |
| Environment_Ambient humidity |
35 to 85%RH, Storage: 35 to 85%RH (no freezing or condensation) |
| Installation |
DIN rail 35 mm |
| Protection structure |
IP20(IEC standard) |
| Material |
Case, cover: PC |
