| Type |
Dual display |
| Display method |
4-digit 7-segment LCD |
| Light source |
Red LED(660nm) |
| Response time |
50㎲, 150㎲, 500㎲, 4ms, 10ms |
| Power voltage |
12-24VDC
|
| Current consumption |
Max. 50mA |
| Operation mode |
Light ON/Dark ON(set by parameter) |
| Control output |
NPN open collector |
| Timer function |
OFF, OFF Delay, ON Delay, One-shot(1 to 5000ms) |
| Sensitivity adjustment |
Manual Teaching(auto-tuning, 1-point, 2-point, positioning) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-10 to 50℃ |
| Protection structure |
IP40 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case: polyketon, cover: polycarbonates |
| Accessories |
Connector type wire (Ø4mm, 4-wire, 2m / AWG22, core diameter: 0.08mm, number of cores: 60, insulator diameter: Ø1.25mm) |
| Weight |
Approx. 115g(approx. 16g) |
