IDEC Ø16 LB Series Pilot Light (Round), LB1P

Description

IDEC LB1P — Ø16 LB Series Pilot Light (Round), genuine IDEC product.

Overview

IDEC control and signaling devices, including pushbuttons, illuminated pushbuttons, selector and key switches, pilot lights, buzzers, control boxes and maintenance parts for Ø8 to Ø30 panel mounting.

Key Features

  • Genuine IDEC control and signaling device
  • Select by mounting hole size, shape, color, contacts and LED voltage
  • Full range of guards, nameplates and replacement parts

Specifications

Part No. Shape Lens Color Rated Voltage (V) Lens Shape Terminal Type Emitting Color Light Source Mounting Hole Diameter (Ømm) Applicable Panel Thickness (mm)
LB1P-1T01A Round Amber DC5 Round (Flush, Ø18) Solder/Tab Terminal Type Amber LED 16 0.5～3.2
LB1P-1T01G Round Green DC5 Round (Flush, Ø18) Solder/Tab Terminal Type Green LED 16 0.5～3.2
LB1P-1T01PW Round Pure White DC5 Round (Flush, Ø18) Solder/Tab Terminal Type Pure White LED 16 0.5～3.2
LB1P-1T01R Round Red DC5 Round (Flush, Ø18) Solder/Tab Terminal Type Red LED 16 0.5～3.2
LB1P-1T01S Round Blue DC5 Round (Flush, Ø18) Solder/Tab Terminal Type Blue LED 16 0.5～3.2
LB1P-1T01VA Round Amber DC5 Round (Flush, Ø18) PCB Terminal Amber LED 16 0.5～3.2
LB1P-1T01VG Round Green DC5 Round (Flush, Ø18) PCB Terminal Green LED 16 0.5～3.2
LB1P-1T01VPW Round Pure White DC5 Round (Flush, Ø18) PCB Terminal Pure White LED 16 0.5～3.2
LB1P-1T01VR Round Red DC5 Round (Flush, Ø18) PCB Terminal Red LED 16 0.5～3.2
LB1P-1T01VS Round Blue DC5 Round (Flush, Ø18) PCB Terminal Blue LED 16 0.5～3.2
LB1P-1T01VY Round Yellow DC5 Round (Flush, Ø18) PCB Terminal Yellow LED 16 0.5～3.2
LB1P-1T01Y Round Yellow DC5 Round (Flush, Ø18) Solder/Tab Terminal Type Yellow LED 16 0.5～3.2
LB1P-1T03A Round Amber AC/DC12 Round (Flush, Ø18) Solder/Tab Terminal Type Amber LED 16 0.5～3.2
LB1P-1T03G Round Green AC/DC12 Round (Flush, Ø18) Solder/Tab Terminal Type Green LED 16 0.5～3.2
LB1P-1T03PW Round Pure White AC/DC12 Round (Flush, Ø18) Solder/Tab Terminal Type Pure White LED 16 0.5～3.2
LB1P-1T03R Round Red AC/DC12 Round (Flush, Ø18) Solder/Tab Terminal Type Red LED 16 0.5～3.2
LB1P-1T03S Round Blue AC/DC12 Round (Flush, Ø18) Solder/Tab Terminal Type Blue LED 16 0.5～3.2
LB1P-1T03VA Round Amber AC/DC12 Round (Flush, Ø18) PCB Terminal Amber LED 16 0.5～3.2
LB1P-1T03VG Round Green AC/DC12 Round (Flush, Ø18) PCB Terminal Green LED 16 0.5～3.2
LB1P-1T03VPW Round Pure White AC/DC12 Round (Flush, Ø18) PCB Terminal Pure White LED 16 0.5～3.2
LB1P-1T03VS Round Blue AC/DC12 Round (Flush, Ø18) PCB Terminal Blue LED 16 0.5～3.2
LB1P-1T03VY Round Yellow AC/DC12 Round (Flush, Ø18) PCB Terminal Yellow LED 16 0.5～3.2
LB1P-1T03Y Round Yellow AC/DC12 Round (Flush, Ø18) Solder/Tab Terminal Type Yellow LED 16 0.5～3.2
LB1P-1T04A Round Amber AC/DC24 Round (Flush, Ø18) Solder/Tab Terminal Type Amber LED 16 0.5～3.2
LB1P-1T04PW Round Pure White AC/DC24 Round (Flush, Ø18) Solder/Tab Terminal Type Pure White LED 16 0.5～3.2
LB1P-1T04S Round Blue AC/DC24 Round (Flush, Ø18) Solder/Tab Terminal Type Blue LED 16 0.5～3.2
LB1P-1T04VA Round Amber AC/DC24 Round (Flush, Ø18) PCB Terminal Amber LED 16 0.5～3.2
LB1P-1T04VG Round Green AC/DC24 Round (Flush, Ø18) PCB Terminal Green LED 16 0.5～3.2
LB1P-1T04VPW Round Pure White AC/DC24 Round (Flush, Ø18) PCB Terminal Pure White LED 16 0.5～3.2
LB1P-1T04VR Round Red AC/DC24 Round (Flush, Ø18) PCB Terminal Red LED 16 0.5～3.2
LB1P-1T04VS Round Blue AC/DC24 Round (Flush, Ø18) PCB Terminal Blue LED 16 0.5～3.2
LB1P-1T04VY Round Yellow AC/DC24 Round (Flush, Ø18) PCB Terminal Yellow LED 16 0.5～3.2
LB1P-2T04A Round Amber AC/DC24 Round (Dome, Ø18) Solder/Tab Terminal Type Amber LED 16 0.5～3.2
LB1P-2T04G Round Green AC/DC24 Round (Dome, Ø18) Solder/Tab Terminal Type Green LED 16 0.5～3.2
LB1P-2T04PW Round Pure White AC/DC24 Round (Dome, Ø18) Solder/Tab Terminal Type Pure White LED 16 0.5～3.2
LB1P-2T04R Round Red AC/DC24 Round (Dome, Ø18) Solder/Tab Terminal Type Red LED 16 0.5～3.2
LB1P-2T04S Round Blue AC/DC24 Round (Dome, Ø18) Solder/Tab Terminal Type Blue LED 16 0.5～3.2
LB1P-2T04VA Round Amber AC/DC24 Round (Dome, Ø18) PCB Terminal Amber LED 16 0.5～3.2
LB1P-2T04VG Round Green AC/DC24 Round (Dome, Ø18) PCB Terminal Green LED 16 0.5～3.2
LB1P-2T04VPW Round Pure White AC/DC24 Round (Dome, Ø18) PCB Terminal Pure White LED 16 0.5～3.2
LB1P-2T04VR Round Red AC/DC24 Round (Dome, Ø18) PCB Terminal Red LED 16 0.5～3.2
LB1P-2T04VS Round Blue AC/DC24 Round (Dome, Ø18) PCB Terminal Blue LED 16 0.5～3.2
LB1P-2T04VY Round Yellow AC/DC24 Round (Dome, Ø18) PCB Terminal Yellow LED 16 0.5～3.2
LB1P-2T04Y Round Yellow AC/DC24 Round (Dome, Ø18) Solder/Tab Terminal Type Yellow LED 16 0.5～3.2

How to Order

Select the exact part number from the options. IDEC part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.

About IDEC

IDEC Corporation is a Japanese manufacturer of industrial automation and safety products, known for its control and signaling devices (pushbuttons, pilot lights, emergency stop switches), relays, terminal blocks, circuit protectors, safety components, PLCs and operator interfaces.

Ordering & Shipping

  • Genuine IDEC product sourced through Korean distribution
  • Lead time varies by model; most items ship within 2-3 weeks
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
