PISCO Lever Chuck

Description

PISCO HC — Lever Chuck, genuine PISCO product.

Overview

Genuine PISCO product.

Key Features

  • Genuine PISCO product
  • Confirm the full part number against your existing part before ordering

Specifications

Part No. Option Operating Temperature Range (˚C) Operating Pressure Range (MPa) Operation Type Repeatability (mm) Fluid Material (Body) Cross-Sectional Area (㎤) RoHS Directive (10 Substances) Port Size Operating Frequency
HC15AR None -10~60 (no freezing) 0.2～0.6 Double-Acting ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15AR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Double-Acting ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15AR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Double-Acting ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15BR None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15BR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15BR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15CR None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15CR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC15CR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20AM None -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20AM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20AR None -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20AR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20AR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BM None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BMX None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast, with Finger Tool Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BMX-WS Jaw Sensor -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast, with Finger Tool Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20BRX-WS Jaw Sensor -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic, with Finger Tool Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20CM None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20CM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20CR None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20CR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC20CR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC30AM None -10~60 (no freezing) 0.2～0.7 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC30AM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.7 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC30BM None -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC30BM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC30CM None -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
HC30CM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.

How to Order

Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.

About PISCO

PISCO (Nihon Pisco) is a Japanese manufacturer of pneumatic components, including push-to-connect fittings, tubing, speed controllers, vacuum pads and ejectors used in factory automation worldwide.

Ordering & Shipping

  • Genuine PISCO product sourced through Korean distribution
  • Lead time varies by model; most items ship within 2-3 weeks
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

PISCO HC — Lever Chuck, genuine PISCO product.OverviewGenuine PISCO product.Key Features Genuine PISCO product Confirm the full part number against... Read more

SKU: HC15AR

$159.22 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal

    Description

    PISCO HC — Lever Chuck, genuine PISCO product.

    Overview

    Genuine PISCO product.

    Key Features

    • Genuine PISCO product
    • Confirm the full part number against your existing part before ordering

    Specifications

    Part No. Option Operating Temperature Range (˚C) Operating Pressure Range (MPa) Operation Type Repeatability (mm) Fluid Material (Body) Cross-Sectional Area (㎤) RoHS Directive (10 Substances) Port Size Operating Frequency
    HC15AR None -10~60 (no freezing) 0.2～0.6 Double-Acting ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15AR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Double-Acting ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15AR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Double-Acting ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15BR None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15BR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15BR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15CR None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15CR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC15CR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 2.1 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20AM None -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20AM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20AR None -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20AR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20AR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BM None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BMX None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast, with Finger Tool Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BMX-WS Jaw Sensor -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast, with Finger Tool Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20BRX-WS Jaw Sensor -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic, with Finger Tool Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20CM None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20CM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20CR None -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20CR-B Mounting Bracket -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC20CR-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.6 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Plastic Cylinder: 4.3 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC30AM None -10~60 (no freezing) 0.2～0.7 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC30AM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.7 Double-Acting Type ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC30BM None -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC30BM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Open ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC30CM None -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.
    HC30CM-S Sensor (with Bracket) -10~60 (no freezing) 0.2～0.7 Single-Acting Normally Closed ±0.1 (at jaw midpoint) Compressed Air (Non-Lubricated) Die Cast Cylinder: 8.8 Compatibility M5×0.8mm Max. / 100 C.P.M.

    How to Order

    Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.

    About PISCO

    PISCO (Nihon Pisco) is a Japanese manufacturer of pneumatic components, including push-to-connect fittings, tubing, speed controllers, vacuum pads and ejectors used in factory automation worldwide.

    Ordering & Shipping

    • Genuine PISCO product sourced through Korean distribution
    • Lead time varies by model; most items ship within 2-3 weeks
    • Ships worldwide from South Korea by FedEx International Priority Express
    • Import duties and taxes are payable by the recipient
    • Bulk and trade pricing available on request
