PISCO push-to-connect fittings, barb fittings, unions, elbows, tees, reducers and plugs for compressed air and vacuum lines.
| Part No. |
Shape |
Material (Body) |
Tube O.D. (Ø) |
Operating Temperature Range (˚C) |
Dimension l (mm) |
Max. Operating Pressure (MPa) |
Dimension A (mm) |
Orifice Dia. (Ømm) |
Dimension E (mm) |
Dimension B (mm) |
Dimension C (mm) |
Fluid |
| SPPL10-02SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
10 |
0～80 (no freezing) |
38.7 |
1.0(at0～20℃) |
11 |
8 |
26.2 |
36 |
Tube End: 20.2 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL10-03SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
10 |
0～80 (no freezing) |
39.4 |
1.0(at0～20℃) |
12 |
8 |
26.2 |
37 |
Tube End: 20.2 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL12-03SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
12 |
0～80 (no freezing) |
43.2 |
1.0(at0～20℃) |
12 |
10 |
29.4 |
39 |
Tube End: 22.9 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL12-04SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
12 |
0～80 (no freezing) |
44.3 |
1.0(at0～20℃) |
15 |
10 |
29.4 |
42 |
Tube End: 22.9 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL4-01SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
4 |
0～80 (no freezing) |
24.3 |
1.0(at0～20℃) |
8 |
2.8 |
18 |
23.3 |
Tube End: 14.9 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL4-02SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
4 |
0～80 (no freezing) |
25.3 |
1.0(at0～20℃) |
11 |
2.8 |
18 |
26.3 |
Tube End: 14.9 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL4-M3SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
4 |
0～80 (no freezing) |
22.3 |
1.0(at0～20℃) |
2.5 |
1.2 |
18 |
19.8 |
Tube End: 14.9 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL4-M5SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
4 |
0～80 (no freezing) |
22.3 |
1.0(at0～20℃) |
3 |
1.8 |
18 |
20.3 |
Tube End: 14.9 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL6-01SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
6 |
0～80 (no freezing) |
27.3 |
1.0(at0～20℃) |
8 |
4.6 |
19.8 |
25 |
Tube End: 16.8 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL6-02SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
6 |
0～80 (no freezing) |
28.2 |
1.0(at0～20℃) |
11 |
4.6 |
19.8 |
28 |
Tube End: 16.8 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL6-03SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
6 |
0～80 (no freezing) |
29.7 |
1.0(at0～20℃) |
12 |
4.6 |
19.8 |
29.8 |
Tube End: 16.8 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL6-M5SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
6 |
0～80 (no freezing) |
25.3 |
1.0(at0～20℃) |
3 |
1.8 |
19.8 |
22 |
Tube End: 16.8 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL8-01SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
8 |
0～80 (no freezing) |
31.3 |
1.0(at0～20℃) |
8 |
6 |
22.7 |
28 |
Tube End: 18.1 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL8-02SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
8 |
0～80 (no freezing) |
32.2 |
1.0(at0～20℃) |
11 |
6 |
22.7 |
31 |
Tube End: 18.1 |
Air, Water, Other Chemicals, etc. (conditional*1) |
| SPPL8-03SP |
Elbow |
Threaded Part: Corrosion-Resistant SUS303 Equivalent |
8 |
0～80 (no freezing) |
33.7 |
1.0(at0～20℃) |
12 |
6 |
22.7 |
32.8 |
Tube End: 18.1 |
Air, Water, Other Chemicals, etc. (conditional*1) |
