Description
PISCO PAW — Double Branch Y, genuine PISCO product.
Overview
Genuine PISCO product.
Key Features
- Genuine PISCO product
- Confirm the full part number against your existing part before ordering
Specifications
| Part No. |
Orifice Dia. (Ømm) |
Cross-Sectional Area (㎟) |
Operating Vacuum Pressure (kPa) |
Tube O.D. (mm) |
Dimension J2 (mm) |
Packaging |
Dimension C (mm) |
Width Across Flats H (mm) |
Dimension J1 (mm) |
Dimension l2 (mm) |
Mass (g) |
Max. Operating Pressure (MPa) |
Type |
Dimension P1 (Ømm) |
Operating Temperature Range (℃) |
Dimension B (mm) |
Shape |
Connection Thread |
Connection Thread Type |
Fluid |
Dimension E (mm) |
Dimension a (mm) |
Color |
Dimension P2 (Ømm) |
Dimension l1 (mm) |
| PAW10-02 |
7.5 |
|
-100 |
|
17 |
|
|
|
|
22 |
104 |
|
Standard Type |
|
0 ~ 60 (no freezing) |
57.8 |
|
1/4 |
|
|
|
11 |
|
23 |
51.8 |
| PAW10-03 |
|
|
-100 |
10 |
17 |
|
|
22 |
|
|
|
|
Standard Type |
17.6 |
0 ~ 60 (no freezing) |
58.8 |
Double Branch Y |
|
|
|
|
|
Release Ring / Resin Body: Black |
23 |
52.4 |
| PAW10-04 |
7.5 |
|
|
10 |
|
|
20.7 |
|
|
|
124 |
1 |
|
17.6 |
|
|
Double Branch Y |
1/2 |
|
Air, Water (conditional) |
|
15 |
|
|
53.6 |
| PAW12-03 |
|
44.4 |
|
|
|
|
|
|
21 |
27.3 |
168 |
1 |
Standard Type |
|
0 ~ 60 (no freezing) |
|
Double Branch Y |
3/8 |
|
Air, Water (conditional) |
37.4 |
|
|
|
|
| PAW12-04 |
|
45.4 |
-100 |
12 |
|
Standard Packaging |
23.4 |
27 |
|
|
|
|
Standard Type |
21 |
|
|
|
|
|
Air, Water (conditional) |
37.4 |
|
Release Ring / Resin Body: Black |
|
|
| PAW6-01 |
3.7 |
|
-100 |
|
12 |
Standard Packaging |
17 |
14 |
|
16.1 |
|
|
Standard Type |
|
|
43.3 |
Double Branch Y |
|
|
Air, Water (conditional) |
|
8 |
|
|
|
| PAW6-02 |
|
7 |
-100 |
6 |
12 |
Standard Packaging |
|
|
|
17.1 |
44 |
|
Standard Type |
12.4 |
|
|
|
|
R |
|
26.2 |
|
|
|
40.3 |
| PAW6-03 |
|
6.9 |
|
6 |
|
Standard Packaging |
17 |
17 |
14 |
|
|
1 |
Standard Type |
|
|
48.3 |
|
3/8 |
|
|
26.2 |
|
|
|
|
| PAW8-02 |
|
|
|
|
|
|
18.2 |
|
15 |
|
|
|
|
14.4 |
0 ~ 60 (no freezing) |
49.2 |
Double Branch Y |
|
R |
Air, Water (conditional) |
29.1 |
|
|
19 |
43.2 |
| PAW8-03 |
|
|
|
8 |
|
|
|
|
|
|
|
1 |
|
14.4 |
0 ~ 60 (no freezing) |
50.2 |
Double Branch Y |
3/8 |
|
|
29.1 |
12 |
Release Ring / Resin Body: Black |
19 |
|
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
