Description
PISCO EQ0 — Quick Exhaust Valve Standard Type, genuine PISCO product.
Overview
PISCO speed controllers, check valves, hand valves, silencers and flow control components for pneumatic circuits.
Key Features
- Genuine PISCO flow control component
- Select by tube OD, thread and flow direction
- Compact design
Specifications
| Part No. |
Connection Dia. (Tube) (Ømm) |
Type |
Shape |
Thread Size R |
Operating Pressure Range (MPa) |
Exhaust Method |
Min. Operating Differential Pressure (MPa) |
Operating Temperature Range (℃) |
Tube O.D. D (Ømm) |
Effective Area (mm2) (Cv) |
Fluid |
| EQ01-C06P01C08 |
8 |
Standard Type |
In Side: Push-to-Connect Fitting Type / Out Side: Taper Pipe Thread Type |
Out Side: R1 / 8 |
0.1 ~ 0.7 |
|
0.05 |
5 ~ 60 (no freezing in piping) |
In Side: 6 |
8 |
Air |
| EQ02-C06P01C10 |
10 |
Standard Type |
In Side: Push-to-Connect Fitting Type / Out Side: Taper Pipe Thread Type |
Out Side: R1 / 8 |
0.1 ~ 0.7 |
|
0.05 |
5 ~ 60 (no freezing in piping) |
In Side: 6 |
16 |
Air |
| EQ02-C08P02C10 |
10 |
Standard Type |
In Side: Push-to-Connect Fitting Type / Out Side: Taper Pipe Thread Type |
Out Side: R1 / 4 |
0.1 ~ 0.7 |
Push-to-Connect Fitting Type |
0.05 |
5 ~ 60 (no freezing in piping) |
In Side: 8 |
16 |
Air |
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
