Description
PISCO PZC — Mini Type Cross C, genuine PISCO product.
Overview
Genuine PISCO product.
Key Features
- Genuine PISCO product
- Confirm the full part number against your existing part before ordering
Specifications
| Part No. |
Dimension E1 (mm) |
Material (Metal Hood)/Finish |
Dimension F2 (mm) |
Dimension E2 (mm) |
Operating Temperature Range (℃) |
Dimension D (Ømm) |
Color |
Release Ring Dimension D1 (mm) |
Mass (g) |
Release Ring Dimension D2 (mm) |
Dimension B1 (mm) |
Shape |
Dimension P (Ømm) |
Fluid |
Max. Operating Pressure (MPa) |
Cross-Sectional Area (㎟) |
Dimension C (mm) |
Type |
Orifice Dia. (Ømm) |
Tube O.D. (mm) |
Dimension F1 (mm) |
Packaging |
Operating Vacuum Pressure (kPa) |
| PZC1/8-3M |
13.05 |
|
5.6 |
|
0 ~ 60 (no freezing) |
|
Release Ring / Resin Body: Black |
|
4.5 |
9.8X7.8 |
|
|
8.0 |
Air |
1.0 |
|
|
|
|
3.0 |
11.2 |
|
-100.0 |
| PZC10-8W |
|
|
|
|
0 ~ 60 (no freezing) |
4.2 |
Release Ring / Resin Body: Light Gray |
|
28.0 |
|
|
Cross C |
|
Air, Water (conditional) |
|
17.4 |
|
Standard Type |
7.0 |
10X8 |
|
Standard Packaging |
-100.0 |
| PZC4-1/8M |
13.05 |
|
5.6 |
|
|
|
Release Ring / Resin Body: Black |
9.8X7.8 |
4.4 |
9.8X7.8 |
|
Cross C |
|
|
|
2.2 |
11.0 |
|
|
4.0 |
|
|
-100.0 |
| PZC4-3M |
13.05 |
|
5.6 |
13.05 |
0 ~ 60 (no freezing) |
|
Release Ring / Resin Body: Black |
|
|
9.8X7.8 |
|
|
8.0 |
|
1.0 |
|
11.0 |
|
|
|
11.2 |
|
-100.0 |
| PZC6-1/8M |
|
Brass (Electroless Nickel Plating) |
6.6 |
|
0 ~ 60 (no freezing) |
|
|
11.8X9.8 |
|
|
|
Cross C |
10.5 |
Air |
1.0 |
|
11.6 |
Mini Type |
|
|
13.2 |
|
-100.0 |
| PZC6-4M |
|
|
6.6 |
|
0 ~ 60 (no freezing) |
|
Release Ring / Resin Body: Black |
|
6.3 |
9.8X7.8 |
29.1 |
Cross C |
|
Air |
1.0 |
|
|
Mini Type |
|
|
13.2 |
|
-100.0 |
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
About PISCO
PISCO (Nihon Pisco) is a Japanese manufacturer of pneumatic components, including push-to-connect fittings, tubing, speed controllers, vacuum pads and ejectors used in factory automation worldwide.
Ordering & Shipping
- Genuine PISCO product sourced through Korean distribution
- Lead time varies by model; most items ship within 2-3 weeks
- Ships worldwide from South Korea by FedEx International Priority Express
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
