Description
PISCO JPS — Pressure Controller Straight, genuine PISCO product.
Overview
Genuine PISCO product.
Key Features
- Genuine PISCO product
- Confirm the full part number against your existing part before ordering
Specifications
| Part No. |
Width Across Flats H (mm) |
Dimension P2 (Ømm) |
Dimension L3 (mm) |
Dimension B (mm) |
Tube O.D. D (Ømm) |
Compatible Tube O.D. D (Ømm) |
Dimension a (mm) |
Operating Pressure Range (MPa) |
Dimension E (mm) |
Fluid |
Thread Size R |
Thread Dimension |
Dimension l1 (mm) |
Set Pressure Range (MPa) |
Operating Temperature Range (℃) |
Dimension P1 (Ømm) |
RoHS Regulation |
Mass (g) |
Shape |
| JPS10-02 |
|
|
|
|
|
10.0 |
|
0 ~ 0.9 |
|
Air |
R1 / 4 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS10-03 |
|
|
|
|
|
10.0 |
|
0 ~ 0.9 |
|
Air |
R3 / 8 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS12-03 |
|
|
|
|
|
12.0 |
|
0 ~ 0.9 |
|
Air |
R3 / 8 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS12-04 |
|
|
|
|
|
12.0 |
|
0 ~ 0.9 |
|
Air |
R1 / 2 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS4-01 |
|
|
|
|
|
4.0 |
|
0 ~ 0.9 |
|
Air |
R1 / 8 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS4-M5 |
|
|
|
|
|
4.0 |
|
0 ~ 0.9 |
|
Air |
M5 × 0.8 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS6-01 |
|
|
|
|
|
6.0 |
|
0 ~ 0.9 |
|
Air |
R1 / 8 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS6-02 |
|
|
|
|
|
6.0 |
|
0 ~ 0.9 |
|
Air |
R1 / 4 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
| JPS6-M5 |
8.0 |
9.8 |
|
max : 38.3 min : 35.2 |
6.0 |
|
|
0 ~ 0.9 |
|
Air |
|
M5 × 0.8 |
|
0.2 ~ 0.6 |
0 ~ 60 |
12.6 |
Supported |
11.0 |
|
| JPS8-01 |
|
|
|
max : 48.2 min : 43.7 |
|
|
8.0 |
0 ~ 0.9 |
15.2 |
Air |
|
R1 / 8 |
max : 44.2 min : 39.7 |
0.2 ~ 0.6 |
0 ~ 60 |
14.6 |
|
23.0 |
Pressure Controller Straight |
| JPS8-02 |
14.0 |
|
33.6 |
max : 52.3 min : 47.8 |
|
|
11.1 |
0 ~ 0.9 |
18.2 |
Air |
|
R1 / 4 |
max : 46.2 min : 41.8 |
|
0 ~ 60 |
14.6 |
|
|
Pressure Controller Straight |
| JPS8-03 |
|
|
|
|
|
8.0 |
|
0 ~ 0.9 |
|
Air |
R3 / 8 |
|
|
0.2 ~ 0.6 |
0 ~ 60 |
|
|
|
Straight |
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
About PISCO
PISCO (Nihon Pisco) is a Japanese manufacturer of pneumatic components, including push-to-connect fittings, tubing, speed controllers, vacuum pads and ejectors used in factory automation worldwide.
Ordering & Shipping
- Genuine PISCO product sourced through Korean distribution
- Lead time varies by model; most items ship within 2-3 weeks
- Ships worldwide from South Korea by FedEx International Priority Express
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
