PISCO KV — Tube Fitting Brass Union Elbow (with Cover), genuine PISCO product.
Overview
PISCO push-to-connect fittings, barb fittings, unions, elbows, tees, reducers and plugs for compressed air and vacuum lines.
Key Features
- Genuine PISCO fitting
- Select by tube OD and connection thread (R, Rc, G, M, UNF)
- Fast one-touch tube connection
Specifications
| Part No. |
Tube O.D. (mm) |
Orifice Dia. (Ømm) |
Cover |
Material (Rubber) |
Max. Operating Pressure (MPa) |
Mass (g) |
Type |
Fluid |
Dimension C2 (mm) |
Shape |
Dimension E (mm) |
Operating Temperature Range (℃) |
Dimension P1 (Ømm) |
Operating Vacuum Pressure (kPa) |
Dimension C1 (mm) |
Dimension P2 (Ømm) |
| KV10 |
10X12 |
|
Cover |
HNBR |
1.0 |
|
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
|
Union Elbow |
29.3 |
0 ~ 100 (no freezing) |
18.5 |
-100.0 |
23.2 |
18.6 |
| KV10-F |
10X12 |
8.0 |
|
FKM |
1.0 |
58.0 |
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
19.5 |
Union Elbow |
29.3 |
0 ~ 120 (no freezing) |
|
|
23.2 |
18.6 |
| KV12 |
12X14 |
9.0 |
Cover |
HNBR |
|
94.0 |
Spatter-Resistant Type |
|
23.0 |
Union Elbow |
33.4 |
0 ~ 100 (no freezing) |
|
-100.0 |
|
21.6 |
| KV12-F |
12X14 |
9.0 |
Cover |
|
1.0 |
94.0 |
Spatter-Resistant Type |
Air, Water (conditional) Heat Transfer Oil (conditional) |
23.0 |
|
33.4 |
0 ~ 120 (no freezing) |
|
-100.0 |
26.3 |
|
| KV4 |
|
2.5 |
Cover |
HNBR |
|
17.0 |
Spatter-Resistant Type |
|
15.0 |
Union Elbow |
20.7 |
|
10.5 |
-100.0 |
17.6 |
10.4 |
| KV4-F |
4X6 |
2.5 |
Cover |
|
|
17.0 |
Spatter-Resistant Type |
Air, Water (conditional) Heat Transfer Oil (conditional) |
15.0 |
|
20.7 |
0 ~ 120 (no freezing) |
10.5 |
|
17.6 |
10.4 |
| KV6 |
6X8 |
4.0 |
Cover |
|
|
23.0 |
Spatter-Resistant Type |
|
16.0 |
|
23.1 |
0 ~ 100 (no freezing) |
12.5 |
-100.0 |
19.5 |
12.4 |
| KV6-F |
|
4.0 |
Cover |
FKM |
1.0 |
|
|
|
16.0 |
Union Elbow |
23.1 |
0 ~ 120 (no freezing) |
12.5 |
-100.0 |
19.5 |
12.4 |
| KV8 |
8X10 |
6.0 |
Cover |
HNBR |
1.0 |
29.0 |
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
|
|
24.8 |
|
14.5 |
-100.0 |
20.2 |
14.4 |
| KV8-F |
8X10 |
6.0 |
|
FKM |
1.0 |
|
Spatter-Resistant Type |
Air, Water (conditional) Heat Transfer Oil (conditional) |
17.0 |
Union Elbow |
24.8 |
|
14.5 |
-100.0 |
20.2 |
|
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
