Description
PISCO KU — Tube Fitting Brass Union Straight (without Cover), genuine PISCO product.
Overview
PISCO push-to-connect fittings, barb fittings, unions, elbows, tees, reducers and plugs for compressed air and vacuum lines.
Key Features
- Genuine PISCO fitting
- Select by tube OD and connection thread (R, Rc, G, M, UNF)
- Fast one-touch tube connection
Specifications
| Part No. |
Dimension P (Ømm) |
Dimension C (mm) |
Mass (g) |
Dimension B (mm) |
Orifice Dia. (Ømm) |
Tube O.D. (mm) |
Shape |
Cover |
Max. Operating Pressure (MPa) |
Fluid |
Operating Temperature Range (℃) |
Operating Vacuum Pressure (kPa) |
Type |
Material (Rubber) |
| KU10-1 |
18.5 |
20.0 |
41.0 |
41.5 |
|
10.0 |
Union Straight |
without Cover |
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 100 (no freezing) |
-100.0 |
|
HNBR |
| KU10-1-F |
18.5 |
20.0 |
41.0 |
41.5 |
8.0 |
10.0 |
|
|
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 120 (no freezing) |
-100.0 |
Spatter-Resistant Type |
FKM |
| KU12-1 |
21.5 |
22.6 |
65.0 |
46.7 |
9.0 |
|
Union Straight |
without Cover |
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
|
-100.0 |
Spatter-Resistant Type |
HNBR |
| KU12-1-F |
21.5 |
22.6 |
65.0 |
46.7 |
9.0 |
12.0 |
|
without Cover |
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 120 (no freezing) |
|
Spatter-Resistant Type |
FKM |
| KU4-1 |
10.5 |
14.5 |
12.0 |
|
2.5 |
4.0 |
Union Straight |
without Cover |
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 100 (no freezing) |
-100.0 |
Spatter-Resistant Type |
HNBR |
| KU4-1-F |
10.5 |
14.5 |
12.0 |
|
2.5 |
4.0 |
Union Straight |
without Cover |
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 120 (no freezing) |
-100.0 |
Spatter-Resistant Type |
|
| KU6-1 |
12.5 |
16.6 |
18.0 |
34.6 |
4.0 |
6.0 |
Union Straight |
without Cover |
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 100 (no freezing) |
-100.0 |
|
|
| KU6-1-F |
12.5 |
16.6 |
18.0 |
34.6 |
4.0 |
6.0 |
Union Straight |
without Cover |
1.0 |
|
0 ~ 120 (no freezing) |
|
Spatter-Resistant Type |
FKM |
| KU8-1 |
14.5 |
17.7 |
|
36.9 |
|
8.0 |
Union Straight |
without Cover |
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 100 (no freezing) |
-100.0 |
Spatter-Resistant Type |
HNBR |
| KU8-1-F |
14.5 |
17.7 |
22.0 |
36.9 |
6.0 |
8.0 |
Union Straight |
|
1.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
0 ~ 120 (no freezing) |
|
Spatter-Resistant Type |
FKM |
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
