Description
PISCO KU — Tube Fitting Brass Union Straight (with Cover), genuine PISCO product.
Overview
PISCO push-to-connect fittings, barb fittings, unions, elbows, tees, reducers and plugs for compressed air and vacuum lines.
Key Features
- Genuine PISCO fitting
- Select by tube OD and connection thread (R, Rc, G, M, UNF)
- Fast one-touch tube connection
Specifications
| Part No. |
Mass (g) |
Fluid |
Dimension C2 (mm) |
Dimension B (mm) |
Shape |
Dimension C1 (mm) |
Type |
Operating Temperature Range (℃) |
Operating Vacuum Pressure (kPa) |
Max. Operating Pressure (MPa) |
Dimension P1 (Ømm) |
Material (Rubber) |
Orifice Dia. (Ømm) |
Dimension P2 (Ømm) |
Cover |
Tube O.D. (mm) |
| KU10 |
51.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
19.5 |
|
|
23.2 |
Spatter-Resistant Type |
0 ~ 100 (no freezing) |
|
1.0 |
18.5 |
HNBR |
8.0 |
|
Cover |
10X12 |
| KU10-F |
51.0 |
|
19.5 |
47.9 |
|
23.2 |
Spatter-Resistant Type |
|
-100.0 |
1.0 |
|
FKM |
8.0 |
18.6 |
Cover |
10X12 |
| KU12 |
80.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
23.0 |
|
Union Straight |
26.3 |
Spatter-Resistant Type |
0 ~ 100 (no freezing) |
-100.0 |
1.0 |
|
|
9.0 |
|
Cover |
12X14 |
| KU12-F |
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
23.0 |
54.1 |
Union Straight |
26.3 |
Spatter-Resistant Type |
|
-100.0 |
1.0 |
21.5 |
|
9.0 |
21.6 |
Cover |
|
| KU4 |
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
|
36.4 |
Union Straight |
17.6 |
Spatter-Resistant Type |
0 ~ 100 (no freezing) |
|
1.0 |
|
HNBR |
2.5 |
10.4 |
Cover |
4X6 |
| KU4-F |
16.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
15.0 |
36.4 |
Union Straight |
17.6 |
Spatter-Resistant Type |
|
-100.0 |
1.0 |
10.5 |
FKM |
|
10.4 |
|
|
| KU6 |
21.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
16.0 |
40.4 |
Union Straight |
|
Spatter-Resistant Type |
0 ~ 100 (no freezing) |
|
1.0 |
12.5 |
|
|
12.4 |
Cover |
6X8 |
| KU6-F |
|
Air, Water (conditional) Heat Transfer Oil (conditional) |
16.0 |
40.4 |
Union Straight |
|
Spatter-Resistant Type |
0 ~ 120 (no freezing) |
-100.0 |
1.0 |
12.5 |
|
4.0 |
12.4 |
|
6X8 |
| KU8 |
|
|
17.0 |
41.9 |
Union Straight |
20.2 |
|
|
-100.0 |
1.0 |
14.5 |
HNBR |
6.0 |
14.4 |
Cover |
8X10 |
| KU8-F |
26.0 |
Air, Water (conditional) Heat Transfer Oil (conditional) |
|
41.9 |
Union Straight |
20.2 |
|
|
|
1.0 |
14.5 |
FKM |
6.0 |
14.4 |
Cover |
8X10 |
How to Order
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
