Genuine PISCO product.
| Part No. |
Repeatability (mm) |
Material (Body) |
Operating Frequency |
Option |
Fluid |
Operating Temperature Range (℃) |
Port Size |
Cross-Sectional Area (㎤) |
Operating Pressure Range (MPa) |
Operation Type |
| HC15AP-S |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 2.1 |
0.2 ~ 0.6 |
Double-Acting |
| HC15CP |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 2.1 |
0.2 ~ 0.6 |
Single-Acting Normally Closed |
| HC15CP-B |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Mounting Bracket |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 2.1 |
0.2 ~ 0.6 |
Single-Acting Normally Closed |
| HC15CP-S |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 2.1 |
0.2 ~ 0.6 |
Single-Acting Normally Closed |
| HC20AD |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.6 |
Double-Acting |
| HC20AD-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.6 |
Double-Acting |
| HC20AP |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.6 |
Double-Acting |
| HC20AP-B |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Mounting Bracket |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.6 |
Double-Acting |
| HC20AP-S |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.6 |
Double-Acting |
| HC20BD |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC20BD-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC20BDX-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC20BP-B |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Mounting Bracket |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC20BP-S |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC20CD |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
| HC20CD-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
| HC20CP |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
| HC20CP-B |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Mounting Bracket |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
| HC20CP-S |
± 0.1 (at jaw midpoint) |
Plastic |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 4.3 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
| HC30AD |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 8.8 |
0.2 ~ 0.7 |
Double-Acting |
| HC30AD-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 8.8 |
0.2 ~ 0.7 |
Double-Acting |
| HC30BD |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 8.8 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC30BD-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 8.8 |
0.2 ~ 0.7 |
Single-Acting Normally Open |
| HC30CD |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
|
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 8.8 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
| HC30CD-S |
± 0.1 (at jaw midpoint) |
Die Casting |
Max. / 100 C.P.M. |
Sensor (with Bracket) |
Compressed Air (Non-Lubricated) |
-10 ~ 60 ℃ (no freezing) |
M5 × 0.8mm |
Cylinder: 8.8 |
0.2 ~ 0.7 |
Single-Acting Normally Closed |
Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
