PISCO Vacuum Generator Straight Centralized Exhaust (VU)

Description

PISCO VU — Vacuum Generator Straight Centralized Exhaust (VU), genuine PISCO product.

Overview

PISCO vacuum pads, pad holders, vacuum ejectors and vacuum accessories for pick-and-place handling.

Key Features

  • Genuine PISCO vacuum component
  • Select by pad diameter, material and mounting
  • Wide range of buffers and fittings

Specifications

Part No. Material (Metal Hood)/Finish Operating Temperature Range Vacuum Port Size V Suction Flow (L/min) Additional Function Fluid Performance Vacuum Level (kPa) Operating Pressure Range Air Supply Port Size P Standard Supply Pressure (MPa) Shape Nozzle Dia.
VUE07-014J Standard Spec 0 ~ 60 ℃ R1 / 8 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa 0.35 Tubular 0.7
VUE07-014J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 10 ~ 10.5 Centralized Exhaust Spec Air -90 ~ 92 0.15 ~ 0.7MPa Ø4 0.35 Tubular 0.7
VUE07-016J Standard Spec 0 ~ 60 ℃ R1 / 8 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø6 0.35 0.7
VUE07-016J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø6 0.35 0.7
VUE07-M54J Standard Spec 0 ~ 60 ℃ M5 × 0.8 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø4 0.35 Tubular 0.7
VUE07-M54J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 10 ~ 10.5 Centralized Exhaust Spec Air -90 ~ 92 0.15 ~ 0.7MPa Ø4 0.35 Tubular 0.7
VUE07-M56J Standard Spec 0 ~ 60 ℃ M5 × 0.8 10 ~ 10.5 Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø6 0.35 Tubular 0.7
VUE07-M56J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø6 0.35 Tubular
VUE07-M64J Standard Spec 0 ~ 60 ℃ M6 × 1 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 Ø4 0.35 Tubular 0.7
VUE07-M64J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 Ø4 0.35 Tubular 0.7
VUE07-M66J 0 ~ 60 ℃ M6 × 1 10 ~ 10.5 Centralized Exhaust Spec Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø6 0.35 Tubular 0.7
VUE07-M66J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 10 ~ 10.5 Air Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa) -90 ~ 92 0.15 ~ 0.7MPa Ø6 0.35 Tubular 0.7
VUH05-014J Standard Spec 0 ~ 60 ℃ R1 / 8 7.0 Centralized Exhaust Spec High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUH05-014J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUH05-016J Standard Spec 0 ~ 60 ℃ R1 / 8 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø6 0.5 0.5
VUH05-016J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular
VUH05-M54J Standard Spec 0 ~ 60 ℃ M5 × 0.8 7.0 Centralized Exhaust Spec High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUH05-M54J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 7.0 Centralized Exhaust Spec Air -90.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUH05-M56J Standard Spec 0 ~ 60 ℃ M5 × 0.8 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø6 Tubular 0.5
VUH05-M56J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUH05-M64J 0 ~ 60 ℃ M6 × 1 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUH05-M64J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUH05-M66J Standard Spec M6 × 1 7.0 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUH05-M66J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -90.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUH07-014J Standard Spec 0 ~ 60 ℃ R1 / 8 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø4 0.5 Tubular
VUH07-014J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa 0.5 Tubular 0.7
VUH07-016J Standard Spec R1 / 8 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.7
VUH07-016J-S3 Copper-Free Spec R1 / 8 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.7
VUH07-M54J Standard Spec 0 ~ 60 ℃ M5 × 0.8 12.5 ~ 13 Centralized Exhaust Spec Air -92 ~ 93 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.7
VUH07-M54J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 12.5 ~ 13 Centralized Exhaust Spec Air -92 ~ 93 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.7
VUH07-M56J Standard Spec 0 ~ 60 ℃ M5 × 0.8 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø6 Tubular 0.7
VUH07-M56J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 Ø6 0.5 Tubular 0.7
VUH07-M64J Standard Spec 0 ~ 60 ℃ M6 × 1 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.7
VUH07-M64J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 12.5 ~ 13 Centralized Exhaust Spec Air High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø4 0.5 Tubular
VUH07-M66J Standard Spec 0 ~ 60 ℃ M6 × 1 12.5 ~ 13 Centralized Exhaust Spec High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.7
VUH07-M66J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 12.5 ~ 13 Centralized Exhaust Spec High Vacuum Type (Rated Supply Pressure: 0.5MPa) -92 ~ 93 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.7
VUL05-014J Standard Spec 0 ~ 60 ℃ R1 / 8 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 Ø4 0.5 Tubular 0.5
VUL05-014J-S3 Copper-Free Spec R1 / 8 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUL05-016J Standard Spec 0 ~ 60 ℃ R1 / 8 12.0 Centralized Exhaust Spec High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUL05-016J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 Tubular 0.5
VUL05-M54J Standard Spec 0 ~ 60 ℃ M5 × 0.8 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUL05-M54J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular
VUL05-M56J Standard Spec 0 ~ 60 ℃ M5 × 0.8 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUL05-M56J-S3 Copper-Free Spec 0 ~ 60 ℃ 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUL05-M64J Standard Spec M6 × 1 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUL05-M64J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 12.0 Centralized Exhaust Spec High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.5
VUL05-M66J Standard Spec 0 ~ 60 ℃ M6 × 1 12.0 Centralized Exhaust Spec High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUL05-M66J-S3 Copper-Free Spec M6 × 1 12.0 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.5
VUL07-014J Standard Spec 0 ~ 60 ℃ 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.7
VUL07-014J-S3 Copper-Free Spec R1 / 8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.7
VUL07-016J Standard Spec 0 ~ 60 ℃ R1 / 8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.7
VUL07-016J-S3 Copper-Free Spec 0 ~ 60 ℃ R1 / 8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 Tubular 0.7
VUL07-M54J Standard Spec 0 ~ 60 ℃ M5 × 0.8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular
VUL07-M54J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 Ø4 0.5 Tubular 0.7
VUL07-M56J Standard Spec 0 ~ 60 ℃ M5 × 0.8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) 0.15 ~ 0.7MPa Ø6 0.5 Tubular 0.7
VUL07-M56J-S3 Copper-Free Spec 0 ~ 60 ℃ M5 × 0.8 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa 0.5 Tubular 0.7
VUL07-M64J Standard Spec 0 ~ 60 ℃ M6 × 1 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø4 Tubular 0.7
VUL07-M64J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 22 ~ 26 Centralized Exhaust Spec Air -66.0 0.15 ~ 0.7MPa Ø4 0.5 Tubular 0.7
VUL07-M66J Standard Spec 0 ~ 60 ℃ M6 × 1 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 0.7
VUL07-M66J-S3 Copper-Free Spec 0 ~ 60 ℃ M6 × 1 22 ~ 26 Centralized Exhaust Spec Air High Flow Type (Rated Supply Pressure: 0.5MPa) -66.0 0.15 ~ 0.7MPa Ø6 0.5 Tubular

How to Order

Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.

About PISCO

PISCO (Nihon Pisco) is a Japanese manufacturer of pneumatic components, including push-to-connect fittings, tubing, speed controllers, vacuum pads and ejectors used in factory automation worldwide.

Ordering & Shipping

  • Genuine PISCO product sourced through Korean distribution
  • Lead time varies by model; most items ship within 2-3 weeks
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

PISCO VU — Vacuum Generator Straight Centralized Exhaust (VU), genuine PISCO product.OverviewPISCO vacuum pads, pad holders, vacuum ejectors and vacuum... Read more

SKU: VUE07-014J

$20.76 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal
