Name: PISCO Vacuum Generator Straight Atmospheric Exhaust (VU)
Brand: PISCO
SKU: VUE07-014A
Price: 18.45 USD

PISCO Vacuum Generator Straight Atmospheric Exhaust (VU)

VendorPISCO

Description

PISCO VU — Vacuum Generator Straight Atmospheric Exhaust (VU), genuine PISCO product.

Overview

PISCO vacuum pads, pad holders, vacuum ejectors and vacuum accessories for pick-and-place handling.

Key Features

Genuine PISCO vacuum component
Select by pad diameter, material and mounting
Wide range of buffers and fittings

Specifications

Part No.	Vacuum Level (kPa)	Fluid	Nozzle Dia.	Operating Pressure Range	Performance	Material (Metal Hood)/Finish	Additional Function	Standard Supply Pressure (MPa)	Vacuum Port Size V	Operating Temperature Range	Air Supply Port Size P	Suction Flow (L/min)	Shape
VUE07-014A	-90 ~ 92	Air	0.7	0.15 ~ 0.7MPa	Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa)	Standard Spec	Disassemblable Type	0.35		0 ~ 60 ℃	Ø4	10 ~ 10.5	Tubular
VUE07-016A	-90 ~ 92	Air		0.15 ~ 0.7MPa	Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa)	Standard Spec	Disassemblable Type	0.35	R1 / 8	0 ~ 60 ℃	Ø6	10 ~ 10.5	Tubular
VUE07-M54A		Air	0.7	0.15 ~ 0.7MPa	Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa)	Standard Spec	Disassemblable Type	0.35	M5 × 0.8	0 ~ 60 ℃	Ø4	10 ~ 10.5	Tubular
VUE07-M56A	-90 ~ 92	Air	0.7	0.15 ~ 0.7MPa	Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa)	Standard Spec	Disassemblable Type	0.35	M5 × 0.8	0 ~ 60 ℃	Ø6	10 ~ 10.5
VUE07-M64A	-90 ~ 92	Air	0.7	0.15 ~ 0.7MPa	Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa)	Standard Spec	Disassemblable Type	0.35		0 ~ 60 ℃	Ø4	10 ~ 10.5	Tubular
VUE07-M66A	-90 ~ 92	Air	0.7	0.15 ~ 0.7MPa	Low Supply Pressure High Vacuum Type (Rated Supply Pressure: 0.35Mpa)	Standard Spec		0.35	M6 × 1	0 ~ 60 ℃	Ø6	10 ~ 10.5	Tubular
VUH05-014A	-90.0	Air	0.5	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	R1 / 8	0 ~ 60 ℃	Ø4	7.0
VUH05-016A	-90.0	Air	0.5	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type		R1 / 8	0 ~ 60 ℃	Ø6	7.0	Tubular
VUH05-M54A	-90.0	Air	0.5	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M5 × 0.8	0 ~ 60 ℃	Ø4		Tubular
VUH05-M56A	-90.0	Air	0.5		High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M5 × 0.8	0 ~ 60 ℃	Ø6	7.0	Tubular
VUH05-M64A	-90.0	Air	0.5		High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1	0 ~ 60 ℃	Ø4	7.0	Tubular
VUH05-M66A		Air	0.5	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1	0 ~ 60 ℃	Ø6	7.0	Tubular
VUH07-014A	-92 ~ 93	Air	0.7	0.15 ~ 0.7MPa		Standard Spec	Disassemblable Type	0.5	R1 / 8	0 ~ 60 ℃	Ø4	12.5 ~ 13	Tubular
VUH07-016A	-92 ~ 93	Air	0.7	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	R1 / 8	0 ~ 60 ℃	Ø6		Tubular
VUH07-M54A	-92 ~ 93	Air	0.7	0.15 ~ 0.7MPa		Standard Spec	Disassemblable Type	0.5	M5 × 0.8	0 ~ 60 ℃	Ø4	12.5 ~ 13	Tubular
VUH07-M56A	-92 ~ 93	Air	0.7	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M5 × 0.8	0 ~ 60 ℃	Ø6		Tubular
VUH07-M64A	-92 ~ 93	Air	0.7	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1		Ø4	12.5 ~ 13	Tubular
VUH07-M66A	-92 ~ 93	Air	0.7	0.15 ~ 0.7MPa	High Vacuum Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1		Ø6	12.5 ~ 13	Tubular
VUL05-014A	-66.0	Air	0.5	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	R1 / 8		Ø4	12.0	Tubular
VUL05-016A	-66.0	Air	0.5	0.15 ~ 0.7MPa		Standard Spec	Disassemblable Type	0.5	R1 / 8	0 ~ 60 ℃	Ø6	12.0	Tubular
VUL05-M54A	-66.0	Air	0.5	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec		0.5	M5 × 0.8	0 ~ 60 ℃	Ø4	12.0	Tubular
VUL05-M56A	-66.0	Air		0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M5 × 0.8	0 ~ 60 ℃	Ø6	12.0	Tubular
VUL05-M64A	-66.0	Air	0.5	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)		Disassemblable Type	0.5	M6 × 1	0 ~ 60 ℃	Ø4	12.0	Tubular
VUL05-M66A	-66.0	Air		0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1	0 ~ 60 ℃	Ø6	12.0	Tubular
VUL07-014A	-66.0	Air	0.7	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	R1 / 8	0 ~ 60 ℃		22 ~ 26	Tubular
VUL07-016A	-66.0	Air		0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	R1 / 8	0 ~ 60 ℃	Ø6	22 ~ 26	Tubular
VUL07-M54A	-66.0	Air	0.7	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M5 × 0.8	0 ~ 60 ℃	Ø4	22 ~ 26
VUL07-M56A	-66.0	Air	0.7	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M5 × 0.8		Ø6	22 ~ 26	Tubular
VUL07-M64A	-66.0	Air	0.7		High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1	0 ~ 60 ℃	Ø4	22 ~ 26	Tubular
VUL07-M66A	-66.0	Air	0.7	0.15 ~ 0.7MPa	High Flow Type (Rated Supply Pressure: 0.5MPa)	Standard Spec	Disassemblable Type	0.5	M6 × 1	0 ~ 60 ℃	Ø6		Tubular

How to Order

Select the exact part number from the options. PISCO part numbers encode color, contacts, LED voltage, terminal type and options, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.

About PISCO

PISCO (Nihon Pisco) is a Japanese manufacturer of pneumatic components, including push-to-connect fittings, tubing, speed controllers, vacuum pads and ejectors used in factory automation worldwide.

Ordering & Shipping

Genuine PISCO product sourced through Korean distribution
Lead time varies by model; most items ship within 2-3 weeks
Ships worldwide from South Korea by FedEx International Priority Express
Import duties and taxes are payable by the recipient
Bulk and trade pricing available on request
