TONE hand sockets, ratchets, extension bars, adapters and handles for professional mechanics and industrial maintenance.
| Part No. |
Compatible Models |
Bolt diameter (Ømm) |
Dimension A (mm) |
Dimension l (mm) |
Dimension D (Ømm) |
Across Flats (mm) |
Bolt size |
| 20UR27T |
|
(High-strength bolt) M16, (Hex bolt) M18 |
|
|
|
27 |
|
| 20UR32T |
|
(High-strength bolt) M20, (Hex bolt) M22 |
|
|
|
32 |
|
| 20UR36T |
|
(High-strength bolt) M22, (Hex bolt) M24 |
|
|
|
36 |
|
| 20UR41T |
|
(High-strength bolt) M24, (Hex bolt) M27 |
|
|
|
41 |
|
| 22UR27T |
TNC22-1T、TNC22-2T(UR221T、UR222T) |
|
59 |
36 |
71 |
27 |
Hex Bolt: M18, High-Strength Bolt: M16 |
| 22UR32T |
TNC22-1T、TNC22-2T(UR221T、UR222T) |
|
59 |
36 |
71 |
32 |
Hex Bolt: M22, High-Strength Bolt: M20 |
| 22UR36T |
TNC22-1T、TNC22-2T(UR221T、UR222T) |
|
65 |
39 |
71 |
36 |
Hex Bolt: M24, High-Strength Bolt: M22 |
| 24UR32T |
TNC24-1T、TNC24-2T(UR241T、UR242T) |
|
65 |
38 |
77 |
32 |
Hex Bolt: M22, High-Strength Bolt: M20 |
| 24UR36T |
TNC24-1T、TNC24-2T(UR241T、UR242T) |
|
73 |
38 |
77 |
36 |
Hex Bolt: M24, High-Strength Bolt: M22 |
| 24UR41T |
TNC24-1T、TNC24-2T(UR241T、UR242T) |
|
73 |
38 |
77 |
41 |
Hex Bolt: M27, High-Strength Bolt: M24 |
| VRU41T |
G211、G212、TN30E-1T、TN30E-2T |
|
125 |
58 |
75 |
41 |
Hex Bolt: M27, High-Strength Bolt: M24 |
| VRU46T |
G211、G212、TN30E-1T、TN30E-2T |
|
125 |
58 |
80 |
46 |
Hex Bolt: M30, High-Strength Bolt: M27 |
| VRU50T |
G211、G212、TN30E-1T、TN30E-2T |
|
125 |
58 |
85 |
50 |
Hex Bolt: M33, High-Strength Bolt: M30 |
Select the exact part number from the options. TONE part numbers encode drive size, size and type, so please check every character against your existing part or drawing. Contact us if you need help identifying a replacement.
