TSUBAKI Sprocket RS50-2C

Description

TSUBAKI RS50-2C — Sprocket RS50-2C, genuine TSUBAKI product.

Overview

This Tsubaki RS50-2C sprocket has hubs on both sides and teeth for double-strand RS50 roller chain. Double-strand chain increases power capacity, and double hubs give secure mounting for heavier loads. It is used in conveyors and industrial drives requiring reliable power transmission. The pilot bore can be machined to the shaft size required.

Key Features

  • Double-strand teeth for RS50
  • Hubs on both sides (Type C)
  • Secure mounting for heavy loads
  • Pilot bore for custom machining

Specifications

Part No. Material No. of Teeth Bore Type Tooth Width (mm) Type Approx. Mass (kg) No. of Strands Pitch Diameter (Dp) (Ømm) Outer Diameter (Do) (Ømm) Chain No. Hub Length L (mm) Hub Diameter DH (mm)
RS50-2C26T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 26 Pilot bore type 8.7 Sprocket 4.9 2 131.7 140 RS50 75 93
RS50-2C26TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 26 Pilot bore type 8.7 Sprocket 4.9 2 131.7 140 RS50 75 93
RS50-2C27T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 27 Pilot bore type 8.7 Sprocket 5.2 2 136.74 145 RS50 75 93
RS50-2C27TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 27 Pilot bore type 8.7 Sprocket 5.2 2 136.74 145 RS50 75 93
RS50-2C28T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 28 Pilot bore type 8.7 Sprocket 6 2 141.79 150 RS50 80 98
RS50-2C28TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 28 Pilot bore type 8.7 Sprocket 6 2 141.79 150 RS50 80 98
RS50-2C30T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 30 Pilot bore type 8.7 Sprocket 6.5 2 151.87 161 RS50 80 98
RS50-2C30TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 30 Pilot bore type 8.7 Sprocket 6.5 2 151.87 161 RS50 80 98
RS50-2C32T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 32 Pilot bore type 8.7 Sprocket 7 2 161.96 171 RS50 80 98
RS50-2C32TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 32 Pilot bore type 8.7 Sprocket 7 2 161.96 171 RS50 80 98
RS50-2C34T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 34 Pilot bore type 8.7 Sprocket 7.5 2 172.05 181 RS50 80 98
RS50-2C34TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 34 Pilot bore type 8.7 Sprocket 7.5 2 172.05 181 RS50 80 98
RS50-2C35T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 35 Pilot bore type 8.7 Sprocket 7.7 2 177.1 186 RS50 80 98
RS50-2C35TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 35 Pilot bore type 8.7 Sprocket 7.7 2 177.1 186 RS50 80 98
RS50-2C36T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 36 Pilot bore type 8.7 Sprocket 8 2 182.15 191 RS50 80 98
RS50-2C36TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 36 Pilot bore type 8.7 Sprocket 8 2 182.15 191 RS50 80 98
RS50-2C38T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 38 Pilot bore type 8.7 Sprocket 8.6 2 192.24 201 RS50 80 98
RS50-2C38TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 38 Pilot bore type 8.7 Sprocket 8.6 2 192.24 201 RS50 80 98
RS50-2C40T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 40 Pilot bore type 8.7 Sprocket 9.1 2 202.33 211 RS50 80 98
RS50-2C40TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 40 Pilot bore type 8.7 Sprocket 9.1 2 202.33 211 RS50 80 98
RS50-2C42T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 42 Pilot bore type 8.7 Sprocket 9.8 2 212.43 221 RS50 80 98
RS50-2C42TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 42 Pilot bore type 8.7 Sprocket 9.8 2 212.43 221 RS50 80 98
RS50-2C45T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 45 Pilot bore type 8.7 Sprocket 10.8 2 227.58 237 RS50 80 98
RS50-2C45TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 45 Pilot bore type 8.7 Sprocket 10.8 2 227.58 237 RS50 80 98
RS50-2C48T Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 48 Pilot bore type 8.7 Sprocket 12 2 242.73 252 RS50 80 98
RS50-2C48TQ Carbon steel for machine structural use (teeth) / rolled steel for general structure (hub) / welded specification 48 Pilot bore type 8.7 Sprocket 12 2 242.73 252 RS50 80 98

How to Order

Specify number of teeth, bore and hub requirements. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
