Description
TSUBAKI BR — Cam Clutch BR Series, genuine TSUBAKI product.
Overview
The Tsubaki Cam Clutch BR series is a one-way clutch designed for high-speed overrunning, using cams that lift off the race during free rotation to reduce wear. It transmits torque in one direction and freewheels in the other. It is used in backstops for conveyors and inclined drives as well as overrunning applications.
Key Features
- Cam lift-off design for high-speed overrunning
- One-way torque transmission
- Low wear during freewheeling
- Available in left- and right-hand versions
Specifications
| Part No. |
Mass (kg) |
Type |
Dim. E (mm) |
Dim. l (mm) |
Bearing Used |
Dim. F (mm) |
| BR100-LH |
23 |
Open type |
143 |
13.7 |
|
143 |
| BR100-RH |
23 |
Open type |
143 |
13.7 |
|
143 |
| BR100P |
60 |
Package type |
240 |
|
6028Z |
|
| BR130-LH |
31 |
Open type |
173 |
13.7 |
|
173 |
| BR130-RH |
31 |
Open type |
173 |
13.7 |
|
173 |
| BR130P |
80 |
Package type |
278 |
|
6032Z |
|
| BR150-LH |
58 |
Open type |
243 |
13.7 |
|
243 |
| BR150-RH |
58 |
Open type |
243 |
13.7 |
|
243 |
| BR150P |
151 |
Package type |
360 |
|
16040 |
|
| BR180-LH |
60 |
Open type |
290 |
15.9 |
|
270 |
| BR180-RH |
60 |
Open type |
290 |
15.9 |
|
270 |
| BR180P |
169 |
Package type |
360 |
|
6844 |
|
| BR190-LH |
65 |
Open type |
310 |
8.9 |
|
286 |
| BR190-RH |
65 |
Open type |
310 |
8.9 |
|
286 |
| BR190P |
193 |
Package type |
380 |
|
6848 |
|
| BR20-LH |
1.3 |
Open type |
40.7 |
5 |
|
40.7 |
| BR20-RH |
1.3 |
Open type |
40.7 |
5 |
|
40.7 |
| BR20P |
3.4 |
Package type |
78 |
|
6907LB |
|
| BR220-LH |
76 |
Open type |
340 |
10.9 |
|
320 |
| BR220-RH |
76 |
Open type |
340 |
10.9 |
|
320 |
| BR220P |
220 |
Package type |
410 |
|
6852 |
|
| BR240-LH |
84 |
Open type |
370 |
10.9 |
|
350 |
| BR240-RH |
84 |
Open type |
370 |
10.9 |
|
350 |
| BR240P |
267 |
Package type |
440 |
|
6856 |
|
| BR25-LH |
1.4 |
Open type |
44.7 |
5 |
|
44.7 |
| BR25-RH |
1.4 |
Open type |
44.7 |
5 |
|
44.7 |
| BR25P |
3.8 |
Package type |
82 |
|
6908LB |
|
| BR30-LH |
1.5 |
Open type |
49.7 |
5 |
|
49.7 |
| BR30-RH |
1.5 |
Open type |
49.7 |
5 |
|
49.7 |
| BR30P |
4.3 |
Package type |
87 |
|
6009LB |
|
| BR35-LH |
1.9 |
Open type |
54.7 |
5 |
|
54.7 |
| BR35-RH |
1.9 |
Open type |
54.7 |
5 |
|
54.7 |
| BR35P |
5.1 |
Package type |
96 |
|
6010LB |
|
| BR40-LH |
2.4 |
Open type |
64.7 |
5 |
|
64.7 |
| BR40-RH |
2.4 |
Open type |
64.7 |
5 |
|
64.7 |
| BR40P |
7.5 |
Package type |
108 |
|
6011LB |
|
| BR45-LH |
2.6 |
Open type |
69.7 |
5 |
|
69.7 |
| BR45-RH |
2.6 |
Open type |
69.7 |
5 |
|
69.7 |
| BR45P |
7.9 |
Package type |
112 |
|
6012LB |
|
| BR50-LH |
4.1 |
Open type |
84.7 |
7 |
|
84.7 |
| BR50-RH |
4.1 |
Open type |
84.7 |
7 |
|
84.7 |
| BR50P |
10.9 |
Package type |
132 |
|
6014LB |
|
| BR60-LH |
7.3 |
Open type |
80 |
7 |
|
80 |
| BR60-RH |
7.3 |
Open type |
80 |
7 |
|
80 |
| BR60P |
17.5 |
Package type |
155 |
|
6016LB |
|
| BR70-LH |
8.1 |
Open type |
95 |
7 |
|
95 |
| BR70-RH |
8.1 |
Open type |
95 |
7 |
|
95 |
| BR70P |
19.5 |
Package type |
165 |
|
6018LB |
|
| BR80-LH |
12 |
Open type |
115 |
12 |
|
115 |
| BR80-RH |
12 |
Open type |
115 |
12 |
|
115 |
| BR80P |
27 |
Package type |
185 |
|
6021Z |
|
| BR90-LH |
16 |
Open type |
135 |
17 |
|
135 |
| BR90-RH |
16 |
Open type |
135 |
17 |
|
135 |
| BR90P |
35 |
Package type |
206 |
|
6024Z |
|
How to Order
Specify size, bore, rotation direction and torque capacity. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
- High-value or heavy item: online checkout is disabled. Please request a quote for freight and pricing.
