TSUBAKI Plastic Cable Carrier (Part 4) - TKP91H56W225R300

Description

TSUBAKI TK — Plastic Cable Carrier, genuine TSUBAKI product.

Overview

This Tsubaki plastic cable carrier guides power cables, signal lines and hoses that move with a machine axis, keeping them at a controlled bending radius. Interlocking resin links are light, quiet and resistant to corrosion, so the carrier needs no lubrication. It is fitted to machine tools, robots, injection molding machines and automated transfer equipment.

Key Features

  • Interlocking resin links are light and quiet
  • Controlled bending radius extends cable life
  • Corrosion-free and needs no lubrication
  • Length adjusted by adding or removing links

Specifications

Part No. Class Type Pitch (mm) Model Type Outer Width (mm) Inner Width (mm) Mounting Dimension (Height) (mm) Max. Travel Stroke (mm) No. of Links
TKP91H56W225R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 261 225 694～714 6.8
TKP91H56W225R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 261 225 794～814 6.8
TKP91H56W225R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 261 225 894～914 6.8
TKP91H56W250R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 286 250 394～414 6.8
TKP91H56W250R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 286 250 494～514 6.8
TKP91H56W250R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 286 250 594～614 6.8
TKP91H56W250R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 286 250 694～714 6.8
TKP91H56W250R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 286 250 794～814 6.8
TKP91H56W250R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 286 250 894～914 6.8
TKP91H56W275R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 311 275 394～414 6.8
TKP91H56W275R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 311 275 494～514 6.8
TKP91H56W275R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 311 275 594～614 6.8
TKP91H56W275R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 311 275 694～714 6.8
TKP91H56W275R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 311 275 794～814 6.8
TKP91H56W275R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 311 275 894～914 6.8
TKP91H56W300R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 336 300 394～414 6.8
TKP91H56W300R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 336 300 494～514 6.8
TKP91H56W300R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 336 300 594～614 6.8
TKP91H56W300R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 336 300 694～714 6.8
TKP91H56W300R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 336 300 794～814 6.8
TKP91H56W300R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 336 300 894～914 6.8
TKP91H56W325R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 361 325 394～414 6.8
TKP91H56W325R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 361 325 494～514 6.8
TKP91H56W325R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 361 325 594～614 6.8
TKP91H56W325R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 361 325 694～714 6.8
TKP91H56W325R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 361 325 794～814 6.8
TKP91H56W325R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 361 325 894～914 6.8
TKP91H56W350R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 386 350 394～414 6.8
TKP91H56W350R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 386 350 494～514 6.8
TKP91H56W350R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 386 350 594～614 6.8
TKP91H56W350R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 386 350 694～714 6.8
TKP91H56W350R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 386 350 794～814 6.8
TKP91H56W350R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 386 350 894～914 6.8
TKP91H56W400R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 436 400 394～414 6.8
TKP91H56W400R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 436 400 494～514 6.8
TKP91H56W400R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 436 400 594～614 6.8
TKP91H56W400R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 436 400 694～714 6.8
TKP91H56W400R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 436 400 794～814 6.8
TKP91H56W400R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 436 400 894～914 6.8
TKP91H56W450R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 486 450 394～414 6.8
TKP91H56W450R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 486 450 494～514 6.8
TKP91H56W450R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 486 450 594～614 6.8
TKP91H56W450R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 486 450 694～714 6.8
TKP91H56W450R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 486 450 794～814 6.8
TKP91H56W450R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 486 450 894～914 6.8
TKP91H56W500R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 536 500 394～414 6.8
TKP91H56W500R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 536 500 494～514 6.8
TKP91H56W500R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 536 500 594～614 6.8
TKP91H56W500R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 536 500 694～714 6.8
TKP91H56W500R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 536 500 794～814 6.8
TKP91H56W500R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H56 536 500 894～914 6.8
TKP91H80W150R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 418～438 8.8
TKP91H80W150R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 518～538 8.8
TKP91H80W150R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 618～638 8.8
TKP91H80W150R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 718～738 8.8
TKP91H80W150R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 818～838 8.8
TKP91H80W150R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 918～938 8.8
TKP91H80W150R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 1018～1038 8.8
TKP91H80W150R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 200 150 1118～1138 8.8
TKP91H80W175R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 418～438 8.8
TKP91H80W175R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 518～538 8.8
TKP91H80W175R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 618～638 8.8
TKP91H80W175R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 718～738 8.8
TKP91H80W175R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 818～838 8.8
TKP91H80W175R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 918～938 8.8
TKP91H80W175R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 1018～1038 8.8
TKP91H80W175R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 225 175 1118～1138 8.8
TKP91H80W200R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 418～438 8.8
TKP91H80W200R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 518～538 8.8
TKP91H80W200R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 618～638 8.8
TKP91H80W200R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 718～738 8.8
TKP91H80W200R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 818～838 8.8
TKP91H80W200R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 918～938 8.8
TKP91H80W200R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 1018～1038 8.8
TKP91H80W200R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 250 200 1118～1138 8.8
TKP91H80W225R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 418～438 8.8
TKP91H80W225R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 518～538 8.8
TKP91H80W225R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 618～638 8.8
TKP91H80W225R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 718～738 8.8
TKP91H80W225R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 818～838 8.8
TKP91H80W225R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 918～938 8.8
TKP91H80W225R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 1018～1038 8.8
TKP91H80W225R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 275 225 1118～1138 8.8
TKP91H80W250R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 418～438 8.8
TKP91H80W250R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 518～538 8.8
TKP91H80W250R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 618～638 8.8
TKP91H80W250R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 718～738 8.8
TKP91H80W250R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 818～838 8.8
TKP91H80W250R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 918～938 8.8
TKP91H80W250R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 1018～1038 8.8
TKP91H80W250R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 300 250 1118～1138 8.8
TKP91H80W275R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 418～438 8.8
TKP91H80W275R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 518～538 8.8
TKP91H80W275R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 618～638 8.8
TKP91H80W275R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 718～738 8.8
TKP91H80W275R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 818～838 8.8
TKP91H80W275R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 918～938 8.8
TKP91H80W275R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 1018～1038 8.8
TKP91H80W275R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 325 275 1118～1138 8.8
TKP91H80W300R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 418～438 8.8

How to Order

Select by inner height and width, bending radius, travel length and cable fill. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

TSUBAKI TK — Plastic Cable Carrier, genuine TSUBAKI product.OverviewThis Tsubaki plastic cable carrier guides power cables, signal lines and hoses... Read more

SKU: TKP91H56W225R300

$29.07 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
