Description
SMC CS2F125-200 — CS2 Series Tie-Rod Air Cylinder, Non-Lube. This code specifies 125mm bore, 200mm stroke, double acting, without auto switch.
Specification — CS2F125-200
| Mounting |
Rod side flange |
| Bore |
125mm |
| Port thread |
Rc |
| Stroke |
200mm |
| Auto switch |
Without auto switch |
| Port size |
1/2 |
| Fluid |
Air |
| Action |
Double acting |
| Cushion |
Air cushion |
| Rod end male thread |
M30X1.5 |
| Min. operating pressure |
0.05 MPa |
| Max. operating pressure |
0.97 MPa |
| Proof pressure |
1.57 MPa |
| Fluid temp. min |
0 ℃ |
| Fluid temp. max |
70 ℃ |
| Ambient temp. min |
0 ℃ |
| Weight |
11,800 g |
Specification values above are for model code CS2F125-200 as published by SMC. A change of one character in the suffix gives a different part, so order by the full code.
About the SMC CS2 series
- Φ180, Φ200, and Φ250 have been added. [New]
- The axial centralized piping type has been added. (ø180, ø200, and ø250 only) [New]
- Lightweight: Weight reduced by up to 65% (39.1 kg 13.4 kg)
- High rigidity (Allowable lateral load: Max. 700 N)
- Improved ease of piping: Centralized piping ports in the axial direction increase piping flexibility.(Axial centralized piping type)
Supply from Korea
Genuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.
