Test Instruments & Gauges

Peacock Standard Dial Gauges; 0.01mm, JIS B 7503 , 57 Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 57 Graduation 0.01mm Range 5mm Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 57 0.01 5 ±0 -50- 100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 57 65 41.5 18.5 53 14.5 20 4 6.5 49

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 0.05mm, and 0.1mm  JMAS 2001 , 307S Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 307S Graduation 0.01mm Range 30mm Small dial face type ( Ø57mm )Contact point ( X-2 )Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 307S 0.01 30 ±0 -50- 100 14 - ±18 - ±25 7 5 2.2   Dimensions (mm) Model A B C D E F G H I 307S 107 89 22 57 17.5 20 5 7 52

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 0.05mm, and 0.1mm  JMAS 2001 , 207S Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 207S Graduation 0.01mm Range 20mm Small dial face type ( Ø53mm )Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 207S 0.01 20 ±0 -50- 100 10 - ±15 - ±20 7 5 2.0   Dimensions (mm) Model A B C D E F G H I 207S 75 50.5 18.5 53 14.5 20 4 6.5 49

Read more less

TECLOCK Rubber / Plastic Hardness Meter GS-709N Features We have a lineup of models that comply with the standards of each country and are compatible with a wide range of materials, including original products. Use For measuring general rubber, soft plastic, etc. Product specifications Specifications / standards JIS K 7215 compliant Type A Measuring range: 0-100 Dimensions (mm) Height x Width x Depth: 104.2 x 60 x 23.5 Measuring range: 0-100

Read more less

TECLOCK Rubber / Plastic Hardness Meter GS-706N Features It is a measuring instrument that detects the hardness of rubber, sponge, felt, plastic, etc. with extremely high accuracy. The compliance standard is JIS K630 (former JIS A type). Use Applicable materials: general rubber, sponge, felt, plastic JIS K 6301 compliant (vulcanized rubber physical test method abolished in August 1998) Old JIS A type Product specifications Specifications / standards Width x Depth x Height: 60 x 23.5 x 107.7 mm Type A From a total of 43 types of lineup, it is possible to select a model that is more suitable for the sample. Spring load value (mN): 539-8385 Measurement range (°): 0 to 100 Minimum scale (°): 1 Needle shape: Tip φ0.79mm 35 ° conical trapezoid Compliant standard: JIS K 6301 Former JIS A type Needle: truncated cone shape

Read more less

TECLOCK Rubber / Plastic Hardness Meter GS-703 Use JIS K 6301 compliant (vulcanized rubber physical test method abolished in August 1998) Old JIS C type Product specifications Specifications / standards Use: For hard rubber Use: For hard rubber

Read more less

TECLOCK Rubber / Plastic Hardness Meter GS-702N Features We have a lineup of models that comply with the standards of each country and are compatible with a wide range of materials, including original products. Use For plastic and hard rubber. Product specifications Specifications / standards Compliant standard: JIS K 7215 Type D Measuring range: 0-100 Use: For hard rubber Dimensions (mm) Height x Width x Depth: 104.2 x 60 x 23.5 Use: For hard rubber Measuring range: 0-100

Read more less

TECLOCK Rubber / Plastic Hardness Meter GS-701N Features The compliant standard is JIS S 6050. We have a lineup of models that comply with the standards of each country and are compatible with a wide range of materials, including original products. Use Applicable materials: soft rubber, film rolls, spinning rolls. For soft rubber, film rolls, spinning rolls JIS S 6050 compliant plastic eraser (eraser) for hardness test. Product specifications Specifications / standards Compliant standard: JIS S 6050 Width x Depth x Height: 60 x 23.5 x 107.7 mm Type C Spring load value (mN): 539-8385 Measurement range (°): 0 to 100 Minimum scale (°): 1 Needle shape: Tip Φ5.08mm Hemispherical Use: For soft rubber Dimensions (mm) Height x Width x Depth: 104.2 x 60 x 23.5

Read more less

TECLOCK Dial Depth Gauge IM-880 As to internal caliper gauge IM-880 series, the distance between contact points facing outside is firstly set at standard dimension with ring gaugeor micrometer. Then, it is measured by inserting contact point into internal dimension part to be measured after its outer dial of which movestogether with rotated bezel is set at “0”. The displacement of indicator from “0” point of outer dial is to be measured at that time. The value addingto the read displacement to standard dimension or deducting it from standard dimension is the dimension of internal diameter. This seriesattaches spare contact point which cam set accurate dimension corresponding to size of internal dimension. External caliper gauge is opposite,namely reading the value by holding work piece with 2 contact points facing outside Internal caliper gauge to measure internal diameter of cylindrical workpiece and recessed groove diameter. It can measure groove diameter of "O" ring by modifying spare contact point. Set dimension within ±1mm (indication range 2mm) can be comparatively measured (880 series) by alternatively using auxiliary spare contact point in accordance with measured dimension. Please set standard dimension within measuring range with micrometer or ring gauge.   Specifications Graduation (mm) Measuring Range (mm) Indicating Range (mm) Indication Error Measuring Force (N) Weight (g) Spare Contact Point Maximum Measuring Depth A (mm) Entrance Diameter Φd (mm)* Groove Depth H (mm) Minimum Groove Width B (mm) Code No. Measuring Range (mm) 0.01 20~35 2 ±20 3 or less 196 ZS-423 20~23 70 15~18 2.5 2.5 ZS-424 22~25 15~18 3.5 ZS-425 24~27 16~19 4 ZS-426 26~29 18~21 4 ZS-427 28~31 20~23 4 ZS-428 30~33 22~25 4 ZS-429 32~35 24~27 4

Read more less

TECLOCK  Small Dial Indicator TM-35-01 Dial Indicator is surely utilized at manufacturing sites where dimensional high accuracy is needed to be confirmed. The graduation (1- graduation )depends on usage and Teclock offers 6 kinds of graduations, namely 0.0005mm, 0.001mm, 0.005mm, 0.01mm, 0.05mm and 0.1mm. The strokesare available from 0.08mm (the shortest) up to 150mm. Dial Indicator is normally not used independent but its stem or lug back is fixed to a jigand holds work piece with the measuring stand and contact point, and displacement volume is read with short hand and pointer. The dial indicatoris applied for direct measurement to measure actual dimension and comparative measurement for measuring displacement volume from a certainstandard dimension. As bezel diameter is small (minimum diameter=36mm), these are suitable to measure at the narrow setting space of production lines and many measuring points by being mounted to the machine. Lifting lever (Option) can be mounted (except for TM-34). In case that flat back is required, add suffix “f” to the end of model number (example =TM-35f). Measuring range 3.5mm, 4mm, 5mm, and 10mm are available in spite of small size. Bezel clamp (Option) can be mounted. Measuring ability can be changed. Model TM-35-01  Type Long-stroke type Graduation 0.1mm Measuring Range 10mm Dimensions Table Model A B C D E F G H I J TM-35-01 32.5 46 39 36.5 10 41.5 19 5 6.2 16.5   Specifications Graduation (mm) Measuring Range (mm) Repeatability (㎛) Indication Error (μm) Hysteresis (㎛) Standard Contact Point Measuring Force(N) We i g h t (g) Adjacent Error 1 Revolution Total Range 0.1 5 5 9 ±13 ±15 6 ZS-014 1.3 or less 70

Read more less

Mitutoyo MT187 – 187 908 Bevel Protractor 12 908 Stainless steel with satin chrome finish Magnifying Glass for easy Vernier Lesung Specifications for this item Brand Name Mitutoyo Ean 4002395376001 , 4946368047409 , 5055413663873 , 0000000000093 Item Volume 0.002 cubic_metres Item Weight 320 grams Measurement System Metric Model Number MT187-908 Number of Items 1 Part Number 187-908

Read more less

Mitutoyo 187-907 Protractor Set/B150 Specifications for this item Brand Name Mitutoyo Ean 4946368047393 Item Volume 0.001 cubic_meters Item Weight 9.9 ounces Model Number MT187-907 Number of Items 1 Part Number 187-907 UNSPSC Code 41110000

Read more less

Mitutoyo 187 – 901 Universal Bevel Protractor – 150 mm 300 mm Blade Length High performance Easy to use 150 mm, 300 mm blade length Specifications for this item Brand Name Mitutoyo Ean 0603908086048 , 4946368047355 Global Trade Identification Number 00603908086048 Item Weight 5.00 kilograms Model Number 187-901 Number of Items 1 Part Number 187-901 Range ,,, Resolution 152.4

Read more less

Mitutoyo 155-905, 8mm to 150mm, 6 Piece Telescoping Gage Set Spring-loaded plunger expands within the bore (or groove), allowing determination of the internal diameter (or groove width) With a knurled clamp Specifications for this item Brand Name Mitutoyo Ean 4946368023632 , 0603908047704 Item Volume 0.001 cubic_meters Item Weight 11.6 ounces Manufacturer Series Number 155-905 Measurement System Inch Model Number 155-905 Number of Items 1 Part Number 155-905

Read more less

Mitutoyo 154-902, 3mm to 13mm, 4 Piece Small Hole Gage Set Gaging surface is fully hardened to insure long tool life Extra long for gaging deep and shallow holes, slots, and similar workpieces Satin chrome finish Specifications for this item Brand Name Mitutoyo Ean 4946368023489 , 0603908047551 Item Volume 0.001 cubic_meters Item Weight 0.010 ounces Manufacturer Series Number 154-902 Measurement System Metric Model Number 154-902 Number of Items 1 Part Number 154-902 UNSPSC Code 41110000

Read more less

Mitutoyo 7315 Dial Thickness Gage, Groove Thickness Blade Anvil, 0-10mm Range Measuring force 1.4N or less Wide range of applications with various types of measuring faces (on the spindle and anvil) Easy to reach lifting lever Groove Thickness Blade Anvil Specifications for this item Brand Name Mitutoyo Display Type Dial Ean 4946368193243 Gradient Spacing 0.01 millimeters Item Weight 0.010 ounces Maximum Measurement 0-10mm Measurement Accuracy +/- 15 micrometer Measurement System Metric Model Number 7315 Number of Items 1 Part Number 7315 Range 0-10mm Resolution 0.01mm Style Dial

Read more less

Mitutoyo 7360 Dial Thickness Gage, Tube Thickness Anvil, 0-10mm Range Measuring force 1.4N or less Wide range of applications with various types of measuring faces (on the spindle and anvil) Easy to reach lifting lever Tube Thickness Anvil Specifications for this item Brand Name Mitutoyo Display Type Dial Ean 4946368193410 Gradient Spacing 0.01 millimeters Item Weight 9.6 ounces Maximum Measurement 0-10mm Measurement Accuracy +/- 15 micrometer Measurement System Metric Model Number 7360 Number of Items 1 Part Number 7360 Range 0-10mm Resolution 0.01mm Style Dial UNSPSC Code 41111601

Read more less

Mitutoyo 7313 Dial Thickness Gage, Lens Thickness Reverse Anvil, 0-10mm Range Measuring force 1.4N or less Wide range of applications with various types of measuring faces (on the spindle and anvil) Easy to reach lifting lever Lens Thickness Reverse Anvil Specifications for this item Brand Name Mitutoyo Display Type Dial Ean 4946368193236 Gradient Spacing 0.01 millimeters Maximum Measurement 0-10mm Measurement Accuracy +/- 15 micrometer Measurement System Metric Model Number 7313 Number of Items 1 Part Number 7313 Range 0-10mm Resolution 0.01mm Style Dial UNSPSC Code 41111601

Read more less

Mitutoyo 7321 Dial Thickness Gauge, 0 mm-10 mm Range Measuring force 1.4N or less Wide range of applications with various types of measuring faces (on the spindle and anvil) Easy to reach lifting lever Flat Anvil Deep Throat Specifications for this item Brand Name Mitutoyo Ean 4946368193281 Global Trade Identification Number 04946368193281 Included Components 1 x 7321 Item Weight 399 grams Measurement Accuracy n/a Model Number 7321 Number of Items 1 Part Number 7321

Read more less

Mitutoyo 513-501T Pocket Type Dial Test Indicator, Full Set, Horizontal Type, 4mm Stem Dia, Yellow Dial, 0-70-0 Reading, 33mm Dial Dia, 0-0.14mm Range Series 513 dial test indicator with reversible measuring direction and adjustable contact point, for measuring surface variations in narrow or recessed areas Units displayed in fractional millimeters (mm), and has a rotating bezel and limit markers Pocket-type indicator with horizontal face parallel to the axis and three dovetail mounts for mounting horizontally or vertically from the front, top, or back of the indicator Jeweled bearings provide high sensitivity and accuracy, reversible measuring direction, and a 220-degree adjustable contact point Meets Japanese Industrial Standard (JIS) B7533-1990 Specifications for this item Brand Name Mitutoyo Colour Yellow Display Type 0-70-0 Ean 4946368383484 Item Diameter 33 millimetres Item Volume 0.001 cubic_metres Item Weight 0.28 grams Manufacturer Series Number Pocket Type Dial Test Indicator Material Steel Measurement Accuracy +/-0.003mm Measurement System Metric Model Number 513-501T Number of Items 1 Part Number 513-501T Range 0-0.14mm Resolution 0.001mm Size 0-0.14mm, 4mm Stem Special Features Jeweled Bearing Stem Outside Diameter 4.0 millimetres Style 0-70-0, 0.001mm Graduation

Read more less

Mitutoyo 513-503T Pocket Type Dial Test Indicator, Full Set, Horizontal Type, 8mm Stem Dia, Yellow Dial, 0-100-0 Reading, 33mm Dial Dia, 0-0.2mm Range Series 513 dial test indicator with reversible measuring direction and adjustable contact point, for measuring surface variations in narrow or recessed areas Units displayed in fractional millimeters (mm), and has a rotating bezel and limit markers Pocket-type indicator with horizontal face parallel to the axis and three dovetail mounts for mounting horizontally or vertically from the front, top, or back of the indicator Jeweled bearings provide high sensitivity and accuracy, reversible measuring direction, and a 220-degree adjustable contact point Meets Japanese Industrial Standard (JIS) B7533-1990 Specifications for this item Brand Name Mitutoyo Colour Yellow Display Type 0-100-0 Ean 4946368383521 Item Diameter 33 millimetres Item Weight 41.0 grams Manufacturer Series Number Pocket Type Dial Test Indicator Material Steel Measurement Accuracy +/-0.003mm Measurement System Metric Model Number 513-503T Number of Items 1 Part Number 513-503T Range 0-0.2mm Resolution 0.002mm Size 0-0.2mm, 8mm Stem Special Features Jeweled Bearing Stem Outside Diameter 8.0 millimetres Style 0-100-0, 0.002mm Graduation

Read more less

Mitutoyo MT513-517T DIAL TEST INDICATOR SET 0-40-0 0.8/0.01MM Series 513 dial test indicator with reversible measuring direction and adjustable contact point, for measuring surface variations in narrow or recessed areas Units displayed in fractional millimeters (mm), and has a rotating bezel and limit markers Horizontal face parallel to the axis of the indicator and three dovetail mounts for mounting horizontally or vertically from the front, top, or back of the indicator Specifications for this item Brand Name Mitutoyo Ean 4946368383651 Item Weight 41.0 grams Manufacturer Series Number Pocket Type Dial Test Indicator Model Number 513-517T Number of Items 1 Part Number 513-517T

Read more less

Mitutoyo 513-444-10A DIAL TI, MID, TILT 1.6 mm, 3 μm Accuracy, 0.01 mm Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676029 Global Trade Identification Number 04946368676029 Included Components Indicator, 2-stems, 3-contact points, clamp ring, plastic case, user manual Manufacturer Series Number 513 Measurement Accuracy 3μm Measurement System US Model Number 513-444-10A Number of Items 1 Part Number 513-444-10A Range 1.6mm Resolution 0.01mm

Read more less

Mitutoyo 513-484-10E DIAL TI, BAS, HOR 0.8 mm, 3 μm Accuracy, 0.01 mm Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675862 Global Trade Identification Number 04946368675862 Included Components Indicator, stem, contact point, clamp ring, plastic case, user manual Manufacturer Series Number 513 Measurement Accuracy 3μm Measurement System US Model Number 513-484-10E Number of Items 1 Part Number 513-484-10E Range 0.8mm Resolution 0.01mm

Read more less

Mitutoyo 513-454-10A DIAL TI, MID, VERT 0.08 mm, 3 μm Accuracy, 0.01 mm ontact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Colour Yellow Display Type Dial Ean 4946368675817 Global Trade Identification Number 04946368675817 Manufacturer Series Number 513 Measurement Accuracy 3μm Measurement System US Model Number 513-454-10A Number of Items 8 Part Number 513-454-10A Range 0.08mm Resolution 0.01mm

Read more less

Mitutoyo 513-445-10A DIAL TI, MID, TILT 0.4 mm, 1 μm Accuracy, 0.02 mm, Yellow (Pack of 7) Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Colour Yellow Display Type Dial Ean 4946368676265 Global Trade Identification Number 04946368676265 Manufacturer Series Number 513 Measurement Accuracy 1μm Measurement System US Model Number 513-445-10A Number of Items 7 Part Number 513-445-10A Range 0.4mm Resolution 0.02mm

Read more less

Mitutoyo 513-455-10A DIAL TI, MID, VERT 0.2 mm, 1 μm Accuracy, 0.002 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676210 Global Trade Identification Number 04946368676210 Included Components Indicator, 2-stems, 3-contact points, clamp ring, swivel clamp, holding bar, plastic case, user manual Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-455-10A Number of Items 1 Part Number 513-455-10A Range 0.2mm Resolution 0.002mm

Read more less

Mitutoyo 513-426-10A DIAL TI, MID, STD 1.5 mm, 3 μm Accuracy, 0.01 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675985 Global Trade Identification Number 04946368675985 Included Components Indicator, 2-stems, 3-contact points, clamp ring, plastic case, user manual Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-426-10A Number of Items 1 Part Number 513-426-10A Range 1.5mm Resolution 0.01mm UNSPSC Code 27111800

Read more less

Mitutoyo 513-415-10A DIAL TI, MID, STD 1.0 mm, 3 μm Accuracy, 0.01 mm, Yellow (Pack of 8) Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Colour Yellow Display Type Dial Ean 4946368675923 Global Trade Identification Number 04946368675923 Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-415-10A Number of Items 8 Part Number 513-415-10A Range 1.0mm Resolution 0.01mm

Read more less

Mitutoyo 513-474-10E DIAL TI, BAS, STD 0.8 mm, 3 μm Accuracy, 0.01 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675749 Global Trade Identification Number 04946368675749 Included Components Indicator, stem, nut, stylus, plastic case, user manual Item Weight 1.12 ounces Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-474-10E Number of Items 1 Part Number 513-474-10E Range 0.8mm Resolution 0.01mm UNSPSC Code 41111630

Read more less

Mitutoyo 513-464-10E DIAL TI, BAS, STD COMP 0.8 mm, 3 μm Accuracy, 0.01 mm, Yellow ontact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675770 Global Trade Identification Number 04946368675770 Included Components Test Indicator, contact point, clamp ring, stem Item Weight 5.4 ounces Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-464-10E Number of Items 1 Part Number 513-464-10E Range 0.8mm Resolution 0.01mm UNSPSC Code 41110000

Read more less

Mitutoyo 513-404T, 0.01mm X 0.8mm Horizontal Test Indicator Set, 0-40-0 Specifications for this item Brand Name Mitutoyo Ean 0603908127673 , 4946368095127 Inside Depth 5.38 inches Item Weight 7.1 ounces Model Number 513-404T Number of Items 1 Part Number 513-404T UNSPSC Code 41111630 UPC 603908127673

Read more less

Mitutoyo 513-404-10A DIAL TI, MID, STD 0.8 mm, 3 μm Accuracy, 0.01 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675695 Global Trade Identification Number 04946368675695 Included Components Test Indicator, contact point, clamp ring, stem Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-404-10A Number of Items 1 Part Number 513-404-10A Range 0.8mm Resolution 0.01mm UNSPSC Code 27111800

Read more less

Mitutoyo 513-466-10E DIAL TI, BAS, STD COMP 0.5 mm, 3 μm Accuracy, 0.01 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675626 Global Trade Identification Number 04946368675626 Included Components Indicator, stem, nut, stylus, plastic case, user manual Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-466-10E Number of Items 1 Part Number 513-466-10E Range 0.5mm Resolution 0.01mm UNSPSC Code 41111630

Read more less

Mitutoyo 513-424-10A DIAL TI, MID, STD 0.5 mm, 3 μm Accuracy, 0.01 mm   Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368675572 Global Trade Identification Number 04946368675572 Included Components Test Indicator, contact point, clamp ring, stem Manufacturer Series Number 513 Measurement Accuracy 3 μm Measurement System US Model Number 513-424-10A Number of Items 1 Part Number 513-424-10A Range 0.5mm Resolution 0.01mm UNSPSC Code 27111800

Read more less

Mitutoyo 513-425-10A DIAL TI, MID, STD 0.6 mm, 1 μm Accuracy, 0.002 mm, Yellow (Pack of 8)   Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Colour Yellow Display Type Dial Ean 4946368676302 Global Trade Identification Number 04946368676302 Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-425-10A Number of Items 8 Part Number 513-425-10A Range 0.6mm Resolution 0.002mm

Read more less

Mitutoyo 513-475E TI 0 .002-0 .2MM/Ruby   Specifications for this item Brand Name Mitutoyo Ean 4946368573625 Item Weight 11.02 pounds Model Number 513-475E Number of Items 1 Part Number 513-475E UNSPSC Code 41110000

Read more less

Mitutoyo 513-465-10E DIAL TI, BAS, STD COMP 0.2 mm, 1 μm Accuracy, 0.002 mm Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676173 Global Trade Identification Number 04946368676173 Included Components Indicator, stem, nut, styli, and case Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-465-10E Number of Items 1 Part Number 513-465-10E Range 0.2mm Resolution 0.002mm UNSPSC Code 41111630

Read more less

Mitutoyo 513-405-10T DIAL TI, Full, STD 0.2 mm, 1 μm Accuracy, 0.002 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676128 Global Trade Identification Number 04946368676128 Included Components Indicator, clamp ring, 3-contact points, 2-stems, swivel clamp, holding bar Item Volume 0.001 cubic_meters Item Weight 9.0 ounces Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-405-10T Number of Items 1 Part Number 513-405-10T Range 0.2mm Resolution 0.002mm UNSPSC Code 41111600

Read more less

Mitutoyo 513-405-10A DIAL TI, MID, STD 0.2 mm, 1 μm Accuracy, 0.002 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676111 Global Trade Identification Number 04946368676111 Included Components Indicator, clamp ring, 3-contact points, 2-stems, swivel clam Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-405-10A Number of Items 1 Part Number 513-405-10A Range 0.2mm Resolution 0.002mm UNSPSC Code 27111800

Read more less

Mitutoyo 513-471-10E DIAL TI, BAS, STD 0.14 mm, 1 μm Accuracy, 0.001 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676074 Global Trade Identification Number 04946368676074 Included Components Indicator, stem, nut, stylus, plastic case, user manual Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-471-10E Number of Items 1 Part Number 513-471-10E Range 0.14mm Resolution 0.001mm UNSPSC Code 27111800

Read more less

Mitutoyo 513-401-10E DIAL TI, BAS, STD 0.14 mm, 1 μm Accuracy, 0.001 mm, Yellow Contact point effective length is printed on the dial face Increased impact resistance and durability of gears and bezel Inspection certificate included with bidirectional evaluation Increased scratch-resistance of crystal Specifications for this item Brand Name Mitutoyo Color Yellow Display Type Dial Ean 4946368676050 Global Trade Identification Number 04946368676050 Included Components Test Indicator, contact point, clamp ring, stem Item Volume 0.001 cubic_meters Item Weight 1.76 ounces Manufacturer Series Number 513 Measurement Accuracy 1 μm Measurement System US Model Number 513-401-10E Number of Items 1 Part Number 513-401-10E Range 0.14mm Resolution 0.001mm UNSPSC Code 41111600

Read more less

Mitutoyo 2124S-10 Standard Dial Indicator, 5 mm (0.5 mm) The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can easily be installed and removed without tools Secure adhesion between the bezel and crystal as well as the use of an O-ring prevents water or oil penetration The spindle is made of high strength quench hardened stainless steel which resists arduous use A carbide contact point is used A special alloy is used for the sector gears to provide improved wear resistance Specifications for this item Brand Name Mitutoyo Ean 4946368423579 Item Weight 4.54 grams Model Number 2124S-10 Number of Items 1 Part Number 2124S-10 Range ,,,

Read more less

Mitutoyo 2119S-10 Dial Indicator, Lug Back Plate Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools. FALSE through screw holes on the frame and secure adhesion between the bezel and the crystal as well as the use of an O-ring prevents water or oil penetration. / Graduation: 0,001 mm Make sure to buy an original Mitutoyo product. This instrument is supplied by Mitutoyo UK. Buying from us means buying original Mitutoyo instruments directly from the JPese premium manufacturer with the outstanding quality, durability and accuracy that you legitimately expect. Specifications for this item Brand Name Mitutoyo Ean 4946368423555 Item Volume 0.001 cubic_metres Item Weight 150 grams Measurement System Metric Model Number 2119S-10 Number of Items 1 Part Number 2119S-10 Range 5 millimeters

Read more less

Mitutoyo 2113S High Resolution Dial Gauge, 2 mm (0.2 mm) Standard 0,001 mm and 0.005 mm graduation dial indicators have a bezel with an outer diameter of diameter 57 mm All Type come with limit marker and a bezel clamp The outer – and lift lever (optional) can be attached on either the left or right side. These parts are easily installed and remove without tools Secure grip between the to bezel and crystal as well as the use of a O-ring prevents water or oil, eindringen The spindle is made from high-strength Quench hardened stainless steel, resistant hardest use A carbide contact point is in use Specifications for this item Brand Name Mitutoyo Ean 4946368423470 Item Weight 200 grams Model Number 2113S-10 Number of Items 1 Part Number 2113S-10

Read more less

Mitutoyo 2109SB-10 Dial Indicator High performance Easy to use Specifications for this item Brand Name Mitutoyo Ean 0603908362128 , 4946368423418 , 5053252776815 Global Trade Identification Number 00603908362128 Included Components 1 x 2109SB-10 Item Weight 204 grams Model Number 2109SB-10 Number of Items 1 Part Number 2109SB-10 Range ,,, UPC 603908362128

Read more less

Mitutoyo 2109S-10 Plunger Type Dial Indicator 0.001 Excellent indication sentivity Jeweled bearing A carbide contact point is provided Range: 0-25 mm Graduation: 0.001mm Specifications for this item Brand Name Mitutoyo Colour White Ean 4946368423401 , 0603908357353 , 0094714734696 Height 6.09 centimeters Included Components Dial Gauge, manual Item Volume 0.001 cubic_meters Item Weight 204 grams Length 12.95 centimeters Manufacturer Series Number 2109S-10 Material aluminum Model Number 2109S-10 Number of Items 1 Part Number 2109S-10 Size 0-1

Read more less

Mitutoyo 3062S-19 Dial Indicator, Lug Back Plate Large-diameter dial face for easy reading Supplied with limit markers and a bezel clamp as standard Graduation: 0,01 mm Make sure to buy an original Mitutoyo product. This instrument is supplied by Mitutoyo UK. Buying from us means buying original Mitutoyo instruments directly from the JPese premium manufacturer with the outstanding quality, durability and accuracy that you legitimately expect. Specifications for this item Brand Name Mitutoyo Ean 4946368524894 Item Volume 0.004 cubic_metres Item Weight 330 grams Measurement System Metric Model Number 3062S-19 Number of Items 1 Part Number 3062S-19 Range 100 millimeters

Read more less
