Test Instruments & Gauges

Niigata Seiki (SK) SUS Feeler Gauge 0.07mmx1m SFG-07-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. specification Size (mm): 0.07 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.005 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.06mmx1m SFG-06-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. specification Size (mm): 0.06 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.005 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) Pin Gauge Set 5.500-6.000mm AA-5B   Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 5.500-6.000 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Package size: 295 x 208 x 75 mm 　1.68 kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 5.000-5.500mm AA-5A   Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 5.000-5.500 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Package size: 295 x 208 x 75 mm 　1.59 kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 4.500-5.000mm AA-4B Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 4.500-5.000 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Package size: 295 x 208 x 75 mm 　1.52 kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 4.000-4.500mm AA-4A Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 4.000-4.500 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Package size: 295 x 208 x 75 mm 　1.44 kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 3.500-4.000mm AA-3B Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 3.500-4.000 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Package size: 295 x 208 x 75 mm 　1.38 kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 3.000-3.500mm AA-3A Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 3.000-3.500 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Package size: 295 x 208 x 75 mm 　1.33 kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 2.50-3.00mm AA-2B Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 2.500-3000 * 0.010mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) pin gauge set 2.00 to 2.50 AA-2A ■ It is the most common pin gauge set.■ All products have been sub-zero processed to prevent aging.■ Because it is a perfect circle, it can be used in all situations.■ It is with aluminum pin vise.[Use]・ Inspection of hole diameter.-As a mold part.-For core blur inspection.・ For R measurement.[Specifications]Set contents: 2.00 to 2.50 (51 0.01 mm steps in total), mass (kg): 1.1Diameter accuracy: ± 0.8 μm, roundness / cylindricity: within 0.5 μm, hardness: 650 HV or more[Caution]・Special sizes are also available Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) pin gauge set 1.50 to 2.00 (51 0.01 mm steps in total) Features It is a general pin gauge set. All products have been sub-zero processed to prevent aging. Since it is a perfect circle, it can be used in all situations. Comes with an aluminum pin vise. Use Inspection of hole diameter. As a mold part. For core blur inspection. For R measurement. Product specifications Specifications / standards Diameter accuracy: ± 0.8 μm Hardness: 650HV or more Set contents: 1.50 to 2.00 (51 0.01 mm steps in total) Material --- Mass / mass unit 1.1kg Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Pin Gauge Set 1.000-1.500mm AA-1A Feature Comes with an aluminum pin vise. Nominal dimensions are printed on the pin gauge. specification Gauge size (mm): 1.000 to 1.500 * 0.010 mm jump size. Quantity: 1 set (51 pieces) Material: Steel Diameter accuracy: ± 0.8 μm Roundness / cylindricity: Within 0.5 μm Hardness: 720HV or more Size: 300 x 195 x 75 mm With pass certificate Product number set content Mass(kg / set) AA-1B 1.50-2.00 (51 0.01mm steps in total) 1.10 AA-2A 2.00-2.50 (51 0.01mm steps in total) 1.10 AA-2B 2.50 to 3.00 (51 0.01mm steps in total) 1.10 AA-3A 3.00 to 3.50 (51 0.01mm steps in total) 1.10 AA-3B 3.50 to 4.00 (51 0.01mm steps in total) 1.30 AA-4A 4.00 to 4.50 (51 0.01mm steps in total) 1.40 AA-4B 4.50 to 5.00 (51 0.01mm steps in total) 1.50 AA-5A 5.00-5.50 (51 0.01mm steps in total) 1.60 AA-5B 5.50 to 6.00 (51 0.01mm steps in total) 1.60 AA-6A 6.00-6.50 (51 0.01mm steps in total) 1.60

Read more less

Niigata Seiki (SK) Welding gauge WGU-8M Features Made of stainless steel, it is resistant to rust and is robust. Undercut measurement is possible. Comes with a bulge measurement function after pressure welding. In compliance with the new standard notified by the Ministry of Land, Infrastructure, Transport and Tourism, a bead straddling width of 53 mm is secured by measuring the difference in level of butt welding. Use For measurement during all welding such as general welding, construction, shipbuilding, and bridges. Product specifications Specifications / standards Angle measuring instrument difference (°): ± 2 Length measuring instrument difference (mm): ± 0.6 Material Stainless steel (SUS420J2) Mass / mass unit 190g

Read more less

Niigata Seiki (SK) Welding gauge WGU-7M Feature Welding essentials! Welding overlay, fillet, leg length, etc. can be measured and undercut depth can be measured in one step! specification Material: Stainless steel (SUS410) Undercut depth measurement: 0 to 25 mm Bevel angle / groove angle measurement: 0-60 ° Mismatch step measurement: Bead straddle width: 42 mm Butt step measurement: 0 to 25 mm Corner meat leg length measurement and bead height control: 0 to 25 mm Fillet throat thickness measurement: 0 to 15 mm, gap measurement: 2 to 5 mm, plate thickness measurement: straightedge Measurement of weld overlay, fillet size and angle, etc. Body mass: 150g Package size: 88 x 20 x 115 mm 　140 g

Read more less

Niigata Seiki (SK) Welding gauge WGU-2S Welding gauge product information ■ Basic explanation  Undercut depth and length can be measured easily, quickly and accurately.   Since the undercut stylus is a screw type, 0 point adjustment is possible.   SK welding gauges are sold online at DCM. We also handle a large number of other measuring tools and measuring instruments. ■ Product description  Length accuracy: ± 0.1mm.   Angle accuracy: ± 2 °.   Undercut measurement range: 0 to 2 mm.   Straightedge scale: 100 mm.

Read more less

Niigata Seiki (SK) Welding gauge WG-5 Feature For speeding up welding work and rationalizing quality control Can measure extra dimensions up to 50 mm Maintaining a sense of stability during measurement by increasing the base thickness Silver finish reduces reflections when taking pictures With a translucent plastic case that is easy to check The latest product in the WG series! Various improvements have been made to conventional products to further improve usability. It boasts the largest extra measurement length of 50 mm (*) among existing welding gauges. (* Including other companies in leg length and throat thickness, according to our research as of July 2012) specification Material: Stainless steel (SUS410) Corner meat leg length measurement: 0 to 50 mm Throat thickness measurement of fillet: 0-50mm Extra height measurement 0-10mm * Bead straddle width: 60mm Mismatch step measurement: 0 to 50 mm * Bead straddle width: 53 mm Depth step measurement: 0 to 50 mm Plate thickness measurement: 0 to 30 mm Measurement of weld overlay, fillet size and misalignment, etc. Body mass: 187g Package size: 141 x 36 x 105 mm 　270 g

Read more less

Niigata Seiki (SK) Welding Gauge WG-3 Feature For speeding up welding work and rationalizing quality control Can measure extra dimensions up to 50 mm Maintaining a sense of stability during measurement by increasing the base thickness Equipped with a rotor, various measurements are possible Silver finish reduces reflections when taking pictures With a translucent plastic case that is easy to check The latest product in the WG series! Various improvements have been made to conventional products to further improve usability. It boasts the largest extra measurement length of 50 mm (*) among existing welding gauges. (* Including other companies in leg length and throat thickness, according to our research as of July 2012) specification Material: Stainless steel (SUS410) Corner meat leg length measurement: 0 to 50 mm Throat thickness measurement of fillet: 0-50mm Extra height measurement 0-10mm * Bead straddle width: 60mm Mismatch step measurement: 0 to 50 mm * Bead straddle width: 53 mm Depth step measurement: 0 to 50 mm Plate thickness measurement: 0-35 mm Undercut depth measurement: 0 to 50 mm Bevel angle measurement: 0-60 ° C Route spacing measurement: 0.5-5 mm Measurement of weld overlay, fillet size and misalignment, gap size, undercut, angle, etc. Body mass: 198g Package size: 141 x 36 x 105 mm 　290 g

Read more less

Niigata Seiki (SK) Welding gauge WG-1 (M) Feature For speeding up welding work and rationalizing quality control, etc. Robust, light and convenient to carry (with vinyl case) Welding essentials! It is a leg length gauge. Welding overlay, fillet, leg length, etc. can be measured in one step! specification Material: Stainless steel (SUS410) Instrumental error of fillet and surplus: ± 0.4 mm Angle measuring instrument difference (bevel angle measurement, etc.): ± 0.7 ° Gap measuring instrument difference: ± 0.4 mm Measurement of weld overlay, fillet size and angle, etc. Body mass: 79g Package size: 105 x 18 x 180 mm 　110 g

Read more less

Niigata Seiki (SK) Protractor No.300 PRT-300S Feature Silver finish Large protractor! Please choose according to the measured object specification Scale: 0.5 ° Maximum measurement angle: 180 ° Accuracy: ± 15' Standard: 300mm Body diameter: 210mm Body thickness: 2.0mm Number of rods: 1 Total length of rod: 500mm Rod thickness: 2.0mm Rod scale: 300mm (1mm through) Angle measurement Body mass: 610g Package size: 150 x 520 x 35 mm 　620 g

Read more less

Niigata Seiki (SK) Protractor No.30 Silver Finish PRT-30S Feature Silver finish A needle is built into the lock nut of the center, which is convenient for pulling out the center. Marking needle 3 inch type. specification Scale: 1 ° Maximum measurement angle: 180 ° Accuracy: ± 20' Body: Diameter 90mm x Thickness 1.2mm Rod: Length 204mm x Thickness 1.2mm Material: Stainless steel (SUS420J2) Angle measurement Body mass: 155g Package size: 70 x 321 x 20 mm 　140 g

Read more less

Niigata Seiki (SK) Taper Gauge Set　TPG-267M Spec Material: Stainless quenching steel (SUS420J2) Standards : 267 M Measurement range (mm): 1 to 29 Instrumental error: (mm): ±0.05 Scale interval (mm): 0.05 Measurement of Mizo, Hole, Hole, etc. Main unit mass: 80g Main unit total length: 144mm Main unit thickness: 1.2mm Package size：45×10×180 mm　90 g

Read more less

Niigata Seiki (SK) Cylindrical taper gauge TPG-710B Product name Niigata Seiki (SK) Cylindrical taper gauge TPG-710B Manufacturer / brand Niigata Seiki Manufacturer model number TPG-710B JAN (EAN) code 4975846007918 Product specifications Specifications: Convenient for quantity inspection of hole diameter, groove diameter, and pipe inner diameter.Application: Measurement of grooves, gaps, hole diameters, etc.Standard: 710BMeasuring range (mm): 4 to 15Instrumental error (mm): ± 0.05

Read more less

Niigata Seiki (SK) Cylindrical taper gauge 1-6mm TPG-710A Feature Silver finish Convenient for quantity inspection of hole diameter, groove diameter, and pipe inner diameter! specification Material: Gauge: Carbon tool steel (TPG-710A), carbon steel for machine structure (TPG-710B, TPG-710C) Grip: Free-cutting steel Standard: 710A Measuring range (mm): 1 to 6 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper, angle: 5 ° 44' Measurement of grooves, gaps, hole diameters, etc. Body mass: 20g Body length: 93mm Package size: 36 x 138 x 13 mm 　20 g

Read more less

Niigata Seiki (SK) Taper gauge 0.4-6mm TPG-270B Feature The inner width is measured using the thickness, and it is a gauge expressed by the scale as it is. It is mainly used when measuring by inserting it into a gap. Silver finish With a PC storage case that is convenient to carry You can easily measure the dimensions of grooves and gaps just by inserting them into the gaps! specification Material: Measurement of grooves, gaps, etc. Measuring range (mm): 0.4 to 6 Instrumental error: (mm): ± 0.04 Scale (mm): 0.05 Taper, angle: 2 ° 51′45 ″ Measurement of grooves, gaps, etc. Body mass: 95g Body length: 160mm Body width: 11mm Package size: 23 x 188 x 15 mm 　90 g

Read more less

Niigata Seiki (SK) Taper gauge # 700 45-60mm TPG-700D Feature Silver finish You can easily measure the dimensions of grooves and gaps just by inserting them into the gaps! specification Material: Stainless hardened steel (SUS420J2) Hardness: HV480 Standard: # 7001-15 Measuring range (mm): 45-60 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper, angle: 7 ° 9′10 ″ Measurement of grooves, gaps, hole diameters, etc. Body mass: 80g Body length: 161.5mm Body thickness: 1.2mm Package size: 80 x 3 x 201 mm 　80 g

Read more less

Niigata Seiki (SK) Taper gauge # 700 30-45mm TPG-700C Feature Silver finish You can easily measure the dimensions of grooves and gaps just by inserting them into the gaps! specification Material: Stainless hardened steel (SUS420J2) Hardness: HV480 Standard: # 7001-15 Measuring range (mm): 30-45 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper, angle: 7 ° 9′10 ″ Measurement of grooves, gaps, hole diameters, etc. Body mass: 60g Body length: 159mm Body thickness: 1.2mm Package size: 56 x 12 x 205 mm 　60 g

Read more less

Niigata Seiki (SK) Taper gauge for right angle measurement TPG-700T Feature A taper gauge dedicated to measuring the inner width. By aligning one side with the measurement surface, more stable measurement can be performed than with a normal taper gauge. Since the scale is on the side during measurement, it is possible to measure in places where the scale cannot be seen from above. specification Material: Stainless hardened steel (SUS420J2) Measuring range (mm): 1 to 15 Instrumental error: (mm): 0.1 Taper, angle: 7 ° 9′10 ″ Measurement of grooves, gaps, etc. Body mass: 10g Body length: 148.5mm Package size: 56 x 6 x 206 mm 　20 g

Read more less

Niigata Seiki (SK) Slide Taper Gauge TPG-700SL Feature Silver finish The clip-type slide case is convenient and safe to carry. The tip of the gauge is R-cut so you can work safely. Can be stored in a sliding manner. You can carry it safely with the clip-type slide case! specification Material: Stainless hardened rope (SUS420J2) Hardness: HV480 Standard: 700SL Measuring range (mm): 1-9 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper, angle: 7 ° 9′10 ″ Length (mm): 135 With clip-type slide case Measurement of grooves, gaps, hole diameters, etc. Body mass: 20g Package size: 55 x 17 x 205 mm 　20 g

Read more less

Niigata Seiki (SK) Caliper 250mm GCC-250 for both inside and outside with scale Feature Unlike ordinary paths, it has a scale so you can read the dimensions directly. It is possible to use with the tips crossed. Since the tip can be crossed and used, it is convenient for measuring outer diameter, inner diameter, thickness, etc. and transferring dimensions! specification Material: Stainless steel (hardened tip), scale (mm): 1, instrumental error (mm): ± 0.5 Measurement of outer diameter, inner diameter, thickness, groove, etc. Body mass: 720g Body A: 367mm Body B: 250mm Body C: 210mm Body D: 2mm Nominal size (mm): 250 Package size: 245 x 27 x 395 mm 　710 g

Read more less

Niigata Seiki (SK) Caliper 200mm GCC-200 for both inside and outside with scale Feature Unlike ordinary paths, it has a scale so you can read the dimensions directly. It is possible to use with the tips crossed. Since the tip can be crossed and used, it is convenient for measuring outer diameter, inner diameter, thickness, etc. and transferring dimensions! specification Material: Stainless steel (hardened tip), scale (mm): 1, instrumental error (mm): ± 0.5 Measurement of outer diameter, inner diameter, thickness, groove, etc. Body mass: 500g Body A: 300mm Body B: 200mm Body C: 190mm Body D: 2mm Nominal size (mm): 200 Package size: 218 x 27 x 318 mm 　510 g

Read more less

Niigata Seiki (SK) Caliper for both inside and outside with scale 150mm GCC-150 Feature Unlike ordinary paths, it has a scale so you can read the dimensions directly. It is possible to use with the tips crossed. Since the tip can be crossed and used, it is convenient for measuring outer diameter, inner diameter, thickness, etc. and transferring dimensions! specification Material: Stainless steel (hardened tip), scale (mm): 1, instrumental error (mm): ± 0.5 Measurement of outer diameter, inner diameter, thickness, groove, etc. Body mass: 250g Body A: 225mm Body B: 150mm Body C: 143mm Body D: 2mm Nominal size (mm): 150 Package size: 145 x 15 x 229 mm 　200 g

Read more less

Niigata Seiki (SK) Caliper 100mm GCC-100 for both inside and outside with scale Feature Unlike ordinary paths, it has a scale so you can read the dimensions directly. It is possible to use with the tips crossed. Since the tip can be crossed and used, it is convenient for measuring outer diameter, inner diameter, thickness, etc. and transferring dimensions! specification Material: Stainless steel (hardened tip), scale (mm): 1, instrumental error (mm): ± 0.5 Measurement of outer diameter, inner diameter, thickness, groove, etc. Body mass: 100g Body A: 152mm Body B: 100mm Body C: 98mm Body D: 2mm Nominal size (mm): 100 Package size: 101 x 15 x 156 mm 　100 g

Read more less

Niigata Seiki (SK) Level Mate　LM-360   Spec Measurement range: 0 - 360 ° Minimum reading: 1 ° reading accuracy: ± 0.5 ° inclination angle of measurement Body Mass: 140g Body Length: 110mm Body width: 110 mm Body Thickness: 20 mm

Read more less

Niigata Seiki (SK) Level Point M LP-360   Feature Direct angle reading with one touch You can measure any angle from horizontal to vertical quickly and accurately. The tip of the punch part has a carbide tip With leg magnet Tilt angle measurement and punching work can be performed at the same time! specification Measurement range: 0 to 360 ° Minimum reading: 1 ° Reading accuracy: Within 1 ° V base compatible diameter: φ20-100mm Tilt angle measurement and punching on a round bar Body mass: 400g Body length: 130mm Body width: 125mm Body thickness: 25mm

Read more less

Peacock Standard Dial Gauges; 0.001mm,  25S ,Range 2mm, Small dial face type( Ø55.7mm ) Model 25S  Graduation 0.001mm  Range 2mm  Small dial face type ( Ø55.7mm ) Lug back Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 25S 0.001 2 0 -100-0 4 ±5 ±6 ±6 ±7 3 0.5 1.5   Dimensions (mm) Model A B C D E F G H I 25S 60 42.6 17 55.7 14.5 20 5 7 52

Read more less

Peacock Standard Dial Gauges; 0.001mm,  25 ,Range 2mm Model 25  Graduation 0.001mm  Range 2mm  Lug back Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 25 0.001 2 ±0 -100-0 4 ±5 ±6 ±6 ±7 3 0.5 1.5   Dimensions (mm) Model A B C D E F G H I 25 72 42 25 66.5 14.5 20 4 7.5 62.5

Read more less

Peacock Standard Dial Gauges; 0.001mm,  5-DX ,Range 1mm Model 5-DX  Graduation 0.001mm  Range 1mm  Durable type (Spindle Ø5mm) Lug back Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 5-DX 0.001 1 0 -100-0 2.5 ±3 ±4 ±4 ±5 3 0.5 1.5   Dimensions (mm) Model A B C D E F G H I 5-DX 60 42.6 17 55.7 14.5 20 5 7 52

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 809, Range 80mm Model 809  Graduation 0.1mm  Range 80mm  Lug back Stem Ø14mm Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 809 0.1 80 ±0 -5-10 50 - ±100 - ±100 - 35 2.5   Dimensions (mm) Model A B C D E F G H I 809 201.5 86.5 54 112 24 22.5 6 10 108

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 507, Range 50mm Model 507  Graduation 0.01mm  Range 50mm  Lug back Stem Ø10mm Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 507 0.01 50 ±0 -50-100 15 - ±20 - ±35 9 5 2.5   Dimensions (mm) Model A B C D E F G H I 507 128 81.5 26.7 81.5 17.5 21.5 5.5 8.5 78.5

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 307, Range 30mm Model 307  Graduation 0.01mm  Range 30mm  Lug back Stem Ø8mm Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 307 0.01 30 ±0 -50-100 14 ±18 ±25 7 5 2.2   Dimensions (mm) Model A B C D E F G H I 307 102 46 22.8 75.5 17.5 21 5 8 72.5

Read more less

Peacock Standard Dial Gauges; 0.01mm , Oil-proof type  , 107-SWA Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 107-SWA  Graduation 0.01mm  Range 10mm  Oil-proof type Flat crystal Contact point ( X-2A ) Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 107-SWA 0.01 10 ±0 -50-100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 107-SWA 65 41.5 18.5 55 15 20 4 6.5 49

Read more less

Peacock Standard Dial Gauges; 0.01mm  JIS B 7503  , 107F-T ,Reversed dial Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 107F-T  Graduation 0.01mm  Range 10mm  Reversed dial Flat back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 107F-T 0.01 10 ±100 -50-0 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 107F-T 65 41.5 18.5 53 14.5 - 4 6.5 49

Read more less

Peacock Standard Dial Gauges; 0.01mm  JIS B 7503  , 107F-RE ,Spindle pull-up release Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 107F-RE Graduation 0.01mm Range 10mm Spindle pull-up release ( RE-1 ) 280 mm longFlat back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 107F-RE 0.01 10 ±0 -50-100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 107F-RE 65 41.5 18.5 53 14.5 20 54 6.5 49

Read more less

Peacock Standard Dial Gauges; 0.01mm  JIS B 7503  , 107-DX Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 107-DX Graduation 0.01mm Range 10mm Durable type ( Spindle Ø5mm )Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 107-DX 0.01 10 ±0 -50-100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 107-DX 65 50.7 17 55.7 14.5 20 5 7 52

Read more less

Peacock Standard Dial Gauges; 0.001mm and 0.005mm  JIS B 7503, 5F Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 5F Graduation 0.001mm Range 1mm Flat back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 5F 0.001 1 0 -100-0 2.5 ±3 ±4 ±4 ±5 3 0.5 1.5   Dimensions (mm) Model A B C D E F G H I 5B 60 41.5 18.5 53 14.5 - 4 6.5 49

Read more less

Peacock Standard Dial Gauges; 0.001mm and 0.005mm  JIS B 7503, 5B Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 5B Graduation 0.001mm Range 1mm Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 5B 0.001 1 0 -100-0 2.5 ±3 ±4 ±4 ±5 3 0.5 1.5   Dimensions (mm) Model A B C D E F G H I 5B 60 41.5 18.5 53 14.5 20 4 6.5 49

Read more less

Peacock Standard Dial Gauges; 0.01mm, JIS B 7503 , 57B Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 57B Graduation 0.01mm Range 5mm Balanced dialFlat back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 57B 0.01 5 ±0 -50- 100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 57B 65 41.5 18.5 53 14.5 - 4 6.5 49

Read more less

Peacock Standard Dial Gauges; 0.01mm, JIS B 7503 , 57F Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way. Model 57F Graduation 0.01mm Range 5mm Flat back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 57F 0.01 5 ±0 -50- 100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 57F 65 41.5 18.5 53 14.5 - 4 6.5 49

Read more less
