Test Instruments & Gauges

Peacock Dial Thickness Gauges G-30 LARGE DIA CONTACT POINT AND ANVIL BEST MEASUREMENT OF Urethane form, common fabric and so on G-30 (30mm dia ; Flat type) Model G-30 Graduation 0.01mm Range 0~10mm Ø30mm flat contact point and anvil (metal)   Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Measuring force less than (N) Dia (mm) Parallelism (µm) G-30 0.01 0~10 20 ±20 30(metal) 20 1.8

Read more less

Peacock Dial Thickness Gauges G-20 LARGE DIA CONTACT POINT AND ANVIL BEST MEASUREMENT OF Urethane form, common fabric and so on G-20 (20mm dia ; Flat type) Model G-20 Graduation 0.01mm Range 0~10mm Ø20mm flat contact point and anvil (metal)   Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Measuring force less than (N) Dia (mm) Parallelism (µm) G-20 0.01 0~10 20 ±20 20(metal) 15 1.8

Read more less

Peacock Dial Thickness Gauges H-30 LARGE DIA CONTACT POINT AND ANVIL BEST MEASUREMENT OF Urethane form, common fabric and so on H-30 (30mm dia ; Flat type) Model H-30 Graduation 0.01mm Range 0~10mm Ø30mm flat contact point and anvil (metal)   Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Measuring force less than (N) Dia (mm) Parallelism (µm) H-30 0.01 0~10 120 ±20 30(metal) 20 1.8

Read more less

Peacock Dial Thickness Gauges G-4 These thickness gauges are especially handy for measuring thickness of small parts, metal, rubber, vinyl, paper, foil and other sheet material.  The objects to be measured is clamped by simple lever operation. The measured values are read directly on the dial gauge.  Since the anvil and the contact point are adjusted for parallelism, accurate measured values are obtained. Model G-4 Graduation 0.01mm Range 65mm (Anvil 55mm) Spherical contact point Anvil side is adjustable   Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Measuring force less than (N) Dia (mm) Parallelism (µm) G-4 0.01 65mm (Anvil 55mm) 30 ±20 ball tip -- 1.8

Read more less

Peacock Dial Thickness Gauges G-3 These thickness gauges are especially handy for measuring thickness of small parts, metal, rubber, vinyl, paper, foil and other sheet material.  The objects to be measured is clamped by simple lever operation. The measured values are read directly on the dial gauge.  Since the anvil and the contact point are adjusted for parallelism, accurate measured values are obtained. Model G-3 Graduation 0.01mm Range 30mm (Anvil 20mm ) Ø10mm flat contact point and anvil (ceramic) Anvil side is adjustable   Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Measuring force less than (N) Dia (mm) Parallelism (µm) G-3 0.01 30 (Anvil 20mm) 20 ±20 10 5 1.8

Read more less

Peacock Dial Thickness Gauges G These thickness gauges are especially handy for measuring thickness of small parts, metal, rubber, vinyl, paper, foil and other sheet material.  The objects to be measured is clamped by simple lever operation. The measured values are read directly on the dial gauge.  Since the anvil and the contact point are adjusted for parallelism, accurate measured values are obtained. Model G Graduation 0.01mm Range 0 - 10mm Ø10mm flat contact point and anvil (ceramic) Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Measuring force less than (N) Dia (mm) Parallelism (µm) G 0.01 0 - 10 20 ±20 10 5 1.8

Read more less

Peacock Linear Gauges Digital Counters, C-700 Model C-700 User friendliness combined with multi-functinality. Multi-type Equipped with large display functions and various measurement functions, our Digital Counters can be installed in a Control Panel or placed on a desk due to their compact designs Specifications of Digital Counters Model C-500 Displayed digits Selection of 10µm  Selection of 1µm Display   -9999.99 - 00.00 - 9999.99 -999.999 - 0.000 - 999.999 High-luminance LED display with 7 segments (red) Power supply voltage & power consumption AC100V -- AC240V / 9VA or lower Operating temperature 0 -- +40ºC Compatible Linear Gauges Selection of 10µm display  Selection of 1µm display   DL-2, D-5, D-10, D-20, D-30, D-50, D-100, DN-10, DN-20, D-5UZ DL-2S, D-5S, D-10S, D-20S, D-30S, D-50S, D-100S DN-10S, DN-20S Accessories AC power cord (2m) ; One cord  Metal fittings for panel installation ; Two units ( to be used for installation in panel and securing stand fittings )  Stand fittings ; One unit ( to be used when counter is used as desktop device ) Terminal block functions ( Rear panel ) Terminal block --> Screwless terminal block  Usable electric cables --> AWG22 - 28  Length of peeled wire of cables --> 8 - 9mm  Pin alignment  (*1) St/Sp Controls "START" and "STOP" of MAX, MIN, P-P measurement mode. (*2) React Controls "SUSPEND" and "START" of P-P measurement mode. 3 Latch Controls "LATCH" and "CANCEL" of measured value. 4 Reset External "RESET" "PRESET" ( Function available only in Model No. C-700 ) 5 Alarm Error signal output 　 Max Min P-P Display Display Display (*6) -NG Outputs -NG based on --> +NG(2) -NG(1) NG(2) OK±NG judgment (red LED). (*7) OK Outputs OK based on --> OK OK OK OK±NG judgment (green LED). (*8) +NG Outputs +NG based on --> +NG(1) -NG(2) NG(1) OK±NG judgment (orange LED). (1) : NG output in first stage(2) : NG output in second stage 9 GND GND (* ) Circled numbers indicate functions available only in Model No. C-700 Dip sw setting functions ( Printed circuit board ) Dip(1) Dip(2)  SW 1 Select 1µm or 10µm  SW 1 Settings by Manufacturer  SW 2 Select direction of counting  SW 2 Select whether or not to include default values for OK±NG judgment  SW 3 Select activation or non-activation of error output.  SW 3 Select either "orthogonal" or "sine" for input waveform.  SW 4 Select activation or non- activation of overflow.  SW 4 Select either 400msec or 100msec for RESET time. Data output (RS-232C) D-Sub9P plug INCH screw 　 Pin Alignment    1  NC -- Communication mode ; Half-duplexasynchronouscommunication   2  Rxd in <-- Communication speed ; 9600bps   3  Txd --> out Format ; 7Bit ASCI I   4  NC -- Parity ; even number   5  SG -- Stop bit ; 1Bit   6  NC -- RTS / CTS ; Returned when not in use.   7  RTS --> out Reception command ; Transmission request ASCI I [T] [t]   8  CTS in <-- ; Reset ASCI I  [R] [r] 　   9  NC -- Connection cables ; Cross cables ( not included )   Options Excel input software :PK-2002  ; Data imported into Excel cells from RS-232C output. BCD output board : CB-BCD  ; Cannot be used in combination with RS-232C output. Display functions 1/1 display --> Displays the measured value as is.  1/2 display --> Displays the measured value after halving it.  ×2 display --> Displays the measured value after doubling it.  Note ; With 1µm display and ×2 display, the lowest digit will be displayed as an even number Presetting display function Can display preset values Measurement mode function Current value display Maximum value (Max) RESET action is taken by ST of the ST/SP control terminal. Minimum value (Min) Deflection (P-P) OK±NG judgment function Current value mode +NG OK   -NG Maximum value mode OK +NG (1) +NG (2) Minimum value mode OK -NG (1) -NG (2) Deflection mode OK NG (1) NG (2) Dimensions/ Weight 144(W)×72(H)×160(D)mm / 950g

Read more less

Peacock Linear Gauges Digital Counters, C-500 Model C-500 Priority on user friendliness. Simple type Equipped with large display functions and various measurement functions, our Digital Counters can be installed in a Control Panel or placed on a desk due to their compact designs Specifications of Digital Counters Model C-500 Displayed digits Selection of 10µm  Selection of 1µm Display   -9999.99 - 00.00 - 9999.99 -999.999 - 0.000 - 999.999 High-luminance LED display with 7 segments (red) Power supply voltage & power consumption AC100V -- AC240V / 9VA or lower Operating temperature 0 -- +40ºC Compatible Linear Gauges Selection of 10µm display  Selection of 1µm display   DL-2, D-5, D-10, D-20, D-30, D-50, D-100, DN-10, DN-20, D-5UZ DL-2S, D-5S, D-10S, D-20S, D-30S, D-50S, D-100S DN-10S, DN-20S Accessories AC power cord (2m) ; One cord  Metal fittings for panel installation ; Two units ( to be used for installation in panel and securing stand fittings )  Stand fittings ; One unit ( to be used when counter is used as desktop device ) Terminal block functions ( Rear panel ) Terminal block --> Screwless terminal block  Usable electric cables --> AWG22 - 28  Length of peeled wire of cables --> 8 - 9mm  Pin alignment  (*1) St/Sp Controls "START" and "STOP" of MAX, MIN, P-P measurement mode. (*2) React Controls "SUSPEND" and "START" of P-P measurement mode. 3 Latch Controls "LATCH" and "CANCEL" of measured value. 4 Reset External "RESET" "PRESET" ( Function available only in Model No. C-700 ) 5 Alarm Error signal output 　 Max Min P-P Display Display Display (*6) -NG Outputs -NG based on --> +NG(2) -NG(1) NG(2) OK±NG judgment (red LED). (*7) OK Outputs OK based on --> OK OK OK OK±NG judgment (green LED). (*8) +NG Outputs +NG based on --> +NG(1) -NG(2) NG(1) OK±NG judgment (orange LED). (1) : NG output in first stage(2) : NG output in second stage 9 GND GND (* ) Circled numbers indicate functions available only in Model No. C-700 Dip sw setting functions ( Printed circuit board ) Dip(1) Dip(2)  SW 1 Select 1µm or 10µm  SW 1 Settings by Manufacturer  SW 2 Select direction of counting  SW 2 Select whether or not to include default values for OK±NG judgment  SW 3 Select activation or non-activation of error output.  SW 3 Select either "orthogonal" or "sine" for input waveform.  SW 4 Select activation or non- activation of overflow.  SW 4 Select either 400msec or 100msec for RESET time. Data output (RS-232C) D-Sub9P plug INCH screw 　 Pin Alignment    1  NC -- Communication mode ; Half-duplexasynchronouscommunication   2  Rxd in <-- Communication speed ; 9600bps   3  Txd --> out Format ; 7Bit ASCI I   4  NC -- Parity ; even number   5  SG -- Stop bit ; 1Bit   6  NC -- RTS / CTS ; Returned when not in use.   7  RTS --> out Reception command ; Transmission request ASCI I [T] [t]   8  CTS in <-- ; Reset ASCI I  [R] [r] 　   9  NC -- Connection cables ; Cross cables ( not included )   Options Excel input software :PK-2002  ; Data imported into Excel cells from RS-232C output. BCD output board : CB-BCD  ; Cannot be used in combination with RS-232C output. Display functions 1/1 display --> Displays the measured value as is.  1/2 display --> Displays the measured value after halving it.  ×2 display --> Displays the measured value after doubling it.  Note ; With 1µm display and ×2 display, the lowest digit will be displayed as an even number Presetting display function Zero setting only Measurement mode function --- OK±NG judgment function --- Dimensions/ Weight 144(W)×72(H)×160(D)mm / 950g

Read more less

Peacock Linear Gauges ; Measurement range 0 - 100mm , D-100S Model D-100S Resolution 0.001mm Range 0 - 100mm With very sturdy ø 20mm stem. Ultra-high precision achievable with exclusive gauge stand (PDS-2) Specifications Model D-100S Range 100mm Resolution 0.001mm Accuracy (excluding quantized error) 0.005mm Measuring force Less than 3.5N Cable length 2m Mounting method ø 20mm stem or fastening by M4 screws at two positions Contact point M2.5 × 0.45 Sø 2.4mm steel Operating temperature 0 - 40ºC Weight 520g Output signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Compatible standard counters C-500 / C-700 / CM-5B Accessories Finger lever for lifting spindle ---> 1 pc Featuares If Spindle inner spring is removed, measuring force will be that of spindle itself (only when in upright position) D-50 , D-50S ---> 1.0N     D-100 , D-100S ---> 1.1N  Recommended stand is PDS-2 Option Level mounting clamp ( GB-50 ) Customer must specify if application is up-side-down.  The measuring force changes when the gauge is inverted.

Read more less

Peacock Linear Gauges ; Measurement range 0 - 100mm , D-100 Model D-100 Resolution 0.01mm Range 0 - 100mm With very sturdy ø 20mm stem. Ultra-high precision achievable with exclusive gauge stand (PDS-2) Specifications Model D-100 Range 100mm Resolution 0.01mm Accuracy (excluding quantized error) 0.01mm Measuring force Less than 3.5N Cable length 2m Mounting method ø 20mm stem or fastening by M4 screws at two positions Contact point M2.5 × 0.45 Sø 2.4mm steel Operating temperature 0 - 40ºC Weight 520g Output signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Compatible standard counters C-500 / C-700 / CM-5B Accessories Finger lever for lifting spindle ---> 1 pc Featuares If Spindle inner spring is removed, measuring force will be that of spindle itself (only when in upright position) D-50 , D-50S ---> 1.0N     D-100 , D-100S ---> 1.1N  Recommended stand is PDS-2 Option Level mounting clamp ( GB-50 ) Customer must specify if application is up-side-down.  The measuring force changes when the gauge is inverted.

Read more less

Peacock Linear Gauges ; Measurement range 0 - 50mm , D-50S Model D-50S Resolution 0.001mm Range 0 - 50mm With very sturdy ø 20mm stem. Ultra-high precision achievable with exclusive gauge stand (PDS-2) Specifications Model D-50S Range 50mm Resolution 0.001mm Accuracy (excluding quantized error) 0.004mm Measuring force Less than 3.0N Cable length 2m Mounting method ø 20mm stem or fastening by M4 screws at two positions Contact point M2.5 × 0.45 Sø 2.4mm steel Operating temperature 0 - 40ºC Weight 450g Output signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Compatible standard counters C-500 / C-700 / CM-5B Accessories Finger lever for lifting spindle ---> 1 pc Featuares If Spindle inner spring is removed, measuring force will be that of spindle itself (only when in upright position) D-50 , D-50S ---> 1.0N     D-100 , D-100S ---> 1.1N  Recommended stand is PDS-2 Option Level mounting clamp ( GB-50 ) Customer must specify if application is up-side-down.  The measuring force changes when the gauge is inverted.

Read more less

Peacock Linear Gauges ; Measurement range 0 - 50mm , D-50 Model D-50 Resolution 0.01mm Range 0 - 50mm With very sturdy ø 20mm stem. Ultra-high precision achievable with exclusive gauge stand (PDS-2) Specifications Model D-50 Range 50mm Resolution 0.01mm Accuracy (excluding quantized error) 0.01mm Measuring force Less than 3.0N Cable length 2m Mounting method ø 20mm stem or fastening by M4 screws at two positions Contact point M2.5 × 0.45 Sø 2.4mm steel Operating temperature 0 - 40ºC Weight 450g Output signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Compatible standard counters C-500 / C-700 / CM-5B Accessories Finger lever for lifting spindle ---> 1 pc Featuares If Spindle inner spring is removed, measuring force will be that of spindle itself (only when in upright position) D-50 , D-50S ---> 1.0N     D-100 , D-100S ---> 1.1N  Recommended stand is PDS-2 Option Level mounting clamp ( GB-50 ) Customer must specify if application is up-side-down.  The measuring force changes when the gauge is inverted.

Read more less

Peacock Linear Gauges ; 10mm range,D-10S  Measurement range (0 - 20mm) 10mm and 20mm measurement ranges are the easiest to use. Used in conjunction with digital counters, these gauges can be set up in places where dial gauges are now being used. Set the gauge by either stem or lug back. For lifting spindle, both lever and release types are available.   Rectangular wave output typ (DN-10/DN-10S/DN-20/DN-20S) For use in electrically noisy environments. For applications requiring extra long cables. (10 to 50 meters are available)   Specifications Model D-10S Range 10mm Resolution 0.001mm Accuracy (excluding quantized error) 0.002mm Measuring force Less than 1.0N Cable length 2m Mounting method Ø8mm stem or 6.5mm hole on lug back Contact point M2.5 × 0.45 SØ2.4mm steel (X-2) Operating temperature 0 - 40ºC Weight 220g Output Signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Rectangular wave (L=0v H=5v) Compatible standard counters C-500 / C-700 CM-5B (*except DN-10S, DN-20S) Options * Release (RE-4)  Lifting lever (LL-1) * Release (RE-4) * Dust proof rubber (BG-10) * Flat back (GB3-D20) * Flat back (GB3-D1O) , screws (S-110) 　 * Customer must specify if application is up-side-down.   The measuring force changes when the gauge is inverted. * Features DN-10 DN-10S DN-20 DN-20S 1. Recommended for locations where cable extension (10 to 50 meters) is necessary. 2. Recommended for use in electrically noisy environments. Notes of wiring : A signal wire should be duct wiring apart from other Power lines.

Read more less

Peacock Linear Gauges ; 20mm range,D-20  Measurement range (0 - 20mm) 10mm and 20mm measurement ranges are the easiest to use. Used in conjunction with digital counters, these gauges can be set up in places where dial gauges are now being used. Set the gauge by either stem or lug back. For lifting spindle, both lever and release types are available.   Rectangular wave output typ (DN-10/DN-10S/DN-20/DN-20S) For use in electrically noisy environments. For applications requiring extra long cables. (10 to 50 meters are available)   Specifications Model D-20 Range 20mm Resolution 0.01mm Accuracy (excluding quantized error) 0.005mm Measuring force Less than 1.5N Cable length 2m Mounting method Ø8mm stem or 6.5mm hole on lug back Contact point M2.5 × 0.45 SØ2.4mm steel (X-2) Operating temperature 0 - 40ºC Weight 300g Output Signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Rectangular wave (L=0v H=5v) Compatible standard counters C-500 / C-700 CM-5B (*except DN-10S, DN-20S) Options * Release (RE-4)  Lifting lever (LL-1) * Release (RE-4) * Dust proof rubber (BG-10) * Flat back (GB3-D20) * Flat back (GB3-D1O) , screws (S-110) 　 * Customer must specify if application is up-side-down.   The measuring force changes when the gauge is inverted. * Features DN-10 DN-10S DN-20 DN-20S 1. Recommended for locations where cable extension (10 to 50 meters) is necessary. 2. Recommended for use in electrically noisy environments. Notes of wiring : A signal wire should be duct wiring apart from other Power lines.

Read more less

Peacock Linear Gauges ; 10mm range,D-10  Measurement range (0 - 20mm) 10mm and 20mm measurement ranges are the easiest to use. Used in conjunction with digital counters, these gauges can be set up in places where dial gauges are now being used. Set the gauge by either stem or lug back. For lifting spindle, both lever and release types are available.   Rectangular wave output typ (DN-10/DN-10S/DN-20/DN-20S) For use in electrically noisy environments. For applications requiring extra long cables. (10 to 50 meters are available)   Specifications Model D-10 Range 10mm Resolution 0.01mm Accuracy (excluding quantized error) 0.005mm Measuring force Less than 1.0N Cable length 2m Mounting method Ø8mm stem or 6.5mm hole on lug back Contact point M2.5 × 0.45 SØ2.4mm steel (X-2) Operating temperature 0 - 40ºC Weight 220g Output Signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Rectangular wave (L=0v H=5v) Compatible standard counters C-500 / C-700 CM-5B (*except DN-10S, DN-20S) Options * Release (RE-4)  Lifting lever (LL-1) * Release (RE-4) * Dust proof rubber (BG-10) * Flat back (GB3-D20) * Flat back (GB3-D1O) , screws (S-110) 　 * Customer must specify if application is up-side-down.   The measuring force changes when the gauge is inverted. * Features DN-10 DN-10S DN-20 DN-20S 1. Recommended for locations where cable extension (10 to 50 meters) is necessary. 2. Recommended for use in electrically noisy environments. Notes of wiring : A signal wire should be duct wiring apart from other Power lines.

Read more less

Peacock Linear Gauges ; Measurement range ( 0 - 5mm ),D-5S Pencil Type Pencil Type D-5S Resolution 0.001mm Range 0～5mm Best suited for confined conditions. (D-5/D-5S)   Specifications Model D-5S Range 5mm Resolution 0.001mm Accuracy (excluding quantized error) 0.002mm Measuring force Less than 0.5N Mounting method ø 8mm stem Contact point Sø 2.4mm cooper (X-2) Cord length 2m Operating temperature 0 - 40ºC Output signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Compatible standard Options C-500 / C-700 CM-5B Options Extension cables of 2, 3, 5, and 10 meters are available (*1) Lever moves linearly, unlike the arc movement in a lever type dial indicator. (*2) Largest deviation value if narrow range for every 0.5mm step.

Read more less

Peacock Linear Gauges ; Measurement range ( 0 - 5mm ),D-5 Pencil Type Pencil Type D-5 Resolution 0.01mm Range 0～5mm Best suited for confined conditions. (D-5/D-5S)   Specifications Model D-5 Range 5mm Resolution 0.01mm Accuracy (excluding quantized error) 0.005mm Measuring force Less than 0.5N Mounting method ø 8mm stem Contact point Sø 2.4mm cooper (X-2) Cord length 2m Operating temperature 0 - 40ºC Output signal 90º phase difference, 20µm pitch (R03-PB8M Tajimi connector) Compatible standard Options C-500 / C-700 CM-5B Options Extension cables of 2, 3, 5, and 10 meters are available (*1) Lever moves linearly, unlike the arc movement in a lever type dial indicator. (*2) Largest deviation value if narrow range for every 0.5mm step.

Read more less

Peacock Signal Gauge SC-2A ( Signal Checker ) Model SC-2A ( Signal Checker ) Measurement range 3.0 mm   Once its tolerance is set, a dial gauge is dismounted before using it so that its endurance is really improved. With its large tolerance setting range of 3mm, it is most suitable for judgement of the measured values ina wide tolerance range. Specifications Model SC-2A Spindle Movable Range 10mm Graduation ※1 Tolerance Setting Range 3.0 mm Accuracy ±0.005mm Measuring Force Less than 1.2N ( 120gf ) Contact capacity MAX DC24V  20mA Number of judgement Stages Three stages of -NG, OK and +NG Cord length 2 m Stem diameter ø8 mm Operating temperature range 0 - 60 ℃ Options Dial gauge for setting Dial indicator for setting Model 107F, 5F Weight 150 g Cable signal table 　 Caution When the current of 10 to 20 mA is used to drive a photocoupler, etc., the contact may be worn a little earlier. In SC-2A type, the COM terminal is body-grounded ( If leak current is found in other devices, put a gauge into floating status before mounting it ). In SC-2A type, a spindle can be set in a range from its free status to 3mm. Although it may be movable in excess of this limit, you cannot set it in such an excessive level in order to protect the spindle. In SC-2A type, when a dial gauge is dismounted after setting the tolerance, never forget to mount a dust protective cap.

Read more less

Peacock Signal Gauge S-9 Model S-9 Graduation 0.05mm Measurement range 3.0 ( ±1.5 ) mm   With its most gross scale of 0.05 mm, it is applicable to select grossly worked parts and as cast parts at the low-est costs Specifications Model S-9 Spindle Movable Range 4mm Graduation 0.05mm Tolerance Setting Range 3.0 ( ±1.5 ) mm Accuracy ±0.025mm Measuring Force Less than 1.2N ( 120gf ) Contact capacity MAX DC24V  20mA Number of judgement Stages Three stages of -NG, OK and +NG Cord length 2 m Stem diameter ø8 mm Operating temperature range 0 - 60 ℃ Options Code Length 5m 10m / Back cover with Lug (GB-1A) Dial indicator for setting ----- Weight 180 g Cable signal table 　 Caution When the current of 10 to 20 mA is used to drive a photocoupler, etc., the contact may be worn a little earlier. In SC-2A type, the COM terminal is body-grounded ( If leak current is found in other devices, put a gauge into floating status before mounting it ). In SC-2A type, a spindle can be set in a range from its free status to 3mm. Although it may be movable in excess of this limit, you cannot set it in such an excessive level in order to protect the spindle. In SC-2A type, when a dial gauge is dismounted after setting the tolerance, never forget to mount a dust protective cap.

Read more less

Peacock Signal Gauge S-7 Model S-7 Graduation 0.01mm Measurement range 1.0 ( ±0.5 ) mm   With its resolution of 0.01mm scale, it is generally used. Its pointer is in an anti-shock structure so as to give stable discriminating signals Specifications Model S-7 Spindle Movable Range 3mm Graduation 0.01mm Tolerance Setting Range 1.0 ( ±0.5 ) mm Accuracy ±0.005mm Measuring Force Less than 1.2N ( 120gf ) Contact capacity MAX DC24V  20mA Number of judgement Stages Three stages of -NG, OK and +NG Cord length 2 m Stem diameter ø8 mm Operating temperature range 0 - 60 ℃ Options Code Length 5m 10m / Back cover with Lug (GB-1A) Dial indicator for setting ----- Weight 180 g Cable signal table 　 Caution When the current of 10 to 20 mA is used to drive a photocoupler, etc., the contact may be worn a little earlier. In SC-2A type, the COM terminal is body-grounded ( If leak current is found in other devices, put a gauge into floating status before mounting it ). In SC-2A type, a spindle can be set in a range from its free status to 3mm. Although it may be movable in excess of this limit, you cannot set it in such an excessive level in order to protect the spindle. In SC-2A type, when a dial gauge is dismounted after setting the tolerance, never forget to mount a dust protective cap.

Read more less

Peacock Signal Gauge S-5 Model S-5 Graduation 0.001mm Measurement range 0.1 ( ±0.05 ) mm   With its high resolution of 0.001mm scale, it is most suitable for  judgement of the values measured on finished parts with high accuracy. Specifications Model S-5 Spindle Movable Range 3mm Graduation 0.001mm Tolerance Setting Range 0.1 ( ±0.05 ) mm Accuracy ±0.002mm Measuring Force Less than 1.2N ( 120gf ) Contact capacity MAX DC24V  20mA Number of judgement Stages Three stages of -NG, OK and +NG Cord length 2 m Stem diameter ø8 mm Operating temperature range 0 - 60 ℃ Options Code Length 5m 10m / Back cover with Lug (GB-1A) Dial indicator for setting ----- Weight 180 g Cable signal table 　 Caution When the current of 10 to 20 mA is used to drive a photocoupler, etc., the contact may be worn a little earlier. In SC-2A type, the COM terminal is body-grounded ( If leak current is found in other devices, put a gauge into floating status before mounting it ). In SC-2A type, a spindle can be set in a range from its free status to 3mm. Although it may be movable in excess of this limit, you cannot set it in such an excessive level in order to protect the spindle. In SC-2A type, when a dial gauge is dismounted after setting the tolerance, never forget to mount a dust protective cap.

Read more less

Peacock Pic test holder, PTH-1,PTH-2

Read more less

Peacock Universal Holder for Test Indicator ,PTH-3,PTH-4

Read more less

Peacock One Revolution Test Indicators (without change lever type), PCN-2ZA The dial face is easy to read with light yellow and blue (dead zone)   Model PCN-2ZA Graduation 0.002mm Range 0.2mm High accuracyContact point (XN2-2) is attached   Graduation (mm) Range (mm) Movable Range (mm) Indication error (µm) Measuring force less than (N) L(mm) Whole measuring range Adjacent error Backward error 0.002 0.2 0.24 3 2 2 0.3 17.8

Read more less

Peacock One Revolution Test Indicators (without change lever type), PCN-1LZAA The dial face is easy to read with light yellow and blue (dead zone)   Model PCN-1LZA Graduation 0.01mm Range 0.8mm Contact point (XN1L-2) is attached   Graduation (mm) Range (mm) Movable Range (mm) Indication error (µm) Measuring force less than (N) L(mm) Whole measuring range Adjacent error Backward error 0.01 0.8 0.9 8 5 4 0.3 42.8

Read more less

Peacock Super low measuring force Test Indicators, PCN-1BE Model PCN-1BE Graduation 0.01mm Range 0.8mm Measuring force 0.05N  Lever dial gauge that is suitable for flaw-free measure of an object under measurement and for measurement of plastic products with a low measuring force. A measuring force is 0.05N, 0.1N or less that is lower than a 0.4N measuring force in the conventional dial gauges. Specifications and outer dimensions are the same as those of standard PC and PCN types, except a measuring force.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L(mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.8 0 - 40 - 0 8 5 3 0.05 22.2

Read more less

Peacock Super low measuring force Test Indicators, PCN-1LE Model PCN-1LE Graduation 0.01mm Range 1.0mm Measuring force 0.05NLong contact point (L = 42.8mm)   Lever dial gauge that is suitable for flaw-free measure of an object under measurement and for measurement of plastic products with a low measuring force. A measuring force is 0.05N, 0.1N or less that is lower than a 0.4N measuring force in the conventional dial gauges. Specifications and outer dimensions are the same as those of standard PC and PCN types, except a measuring force.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L(mm) Wide-range forward accuracy Adjacent error Backward error 0.01 1 0 - 50 - 0 10 5 4 0.05 42.8

Read more less

Peacock Non-electrifying & Complete Anti-magnetic, PCN-6U Test Indicators (Vertical) Model PCN-6U Graduation 0.002mm Range 0.28mm  High accuracy When non-electrifying type of Pic Test or New Pic Test is used, electric flow is blocked at the ceramic stem, even of a magnetic stand is electrified. Thus, you can continue your work without any problem. The dial face is light blue color and easy to read. Specifications and outer dimensions are the same as those of standard PC and PCN types, except the portion of stems Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.002 0.28 0 - 140 - 0 3 2 2 0.3 17.8

Read more less

Peacock Non-electrifying & Complete Anti-magnetic, PCN-5U Test Indicators (Vertical) Model PCN-5U Graduation 0.01mm Range 0.5mm  High accuracy When non-electrifying type of Pic Test or New Pic Test is used, electric flow is blocked at the ceramic stem, even of a magnetic stand is electrified. Thus, you can continue your work without any problem. The dial face is light blue color and easy to read. Specifications and outer dimensions are the same as those of standard PC and PCN types, except the portion of stems Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.5 0 - 25 - 0 5 5 3 0.3 21.3

Read more less

Peacock Non-electrifying & Complete Anti-magnetic, PCN-SU Test Indicators Model PCN-SU Graduation 0.001mm Range 0.14mm  High accuracy When non-electrifying type of Pic Test or New Pic Test is used, electric flow is blocked at the ceramic stem, even of a magnetic stand is electrified. Thus, you can continue your work without any problem. The dial face is light blue color and easy to read. Specifications and outer dimensions are the same as those of standard PC and PCN types, except the portion of stems Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.001 0.14 0 - 70 - 0 3 2 2 0.3 11.7

Read more less

Peacock Non-electrifying & Complete Anti-magnetic, PCN-1BU Test Indicators Model PCN-1BU Graduation 0.01mm Range 0.8mm   When non-electrifying type of Pic Test or New Pic Test is used, electric flow is blocked at the ceramic stem, even of a magnetic stand is electrified. Thus, you can continue your work without any problem. The dial face is light blue color and easy to read. Specifications and outer dimensions are the same as those of standard PC and PCN types, except the portion of stems Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.8 0 - 40 - 0 8 5 3 0.3 22.2

Read more less

Peacock Non-electrifying & Complete Anti-magnetic, PCN-1AU Test Indicators Model PCN-1AU Graduation 0.01mm Range 0.5mm   When non-electrifying type of Pic Test or New Pic Test is used, electric flow is blocked at the ceramic stem, even of a magnetic stand is electrified. Thus, you can continue your work without any problem. The dial face is light blue color and easy to read. Specifications and outer dimensions are the same as those of standard PC and PCN types, except the portion of stems Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.5 0 - 25 - 0 5 5 3 0.3 21.3

Read more less

Peacock Special Type Test Indicators ; Large dial face ,PCN-2BD Model PCN-2BD Graduation 0.002mm Range 0.2mm   The dial plate size of PCN-1A, PCN-1L, and PCN-2BD models has been enlarged, with easy reading due to the lager scale spacing, as a result. Screw type long stems are standard for these large dial face test indicators. Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.002 0.2 0 - 100 - 0 3 2 2 0.3 16.6

Read more less

Peacock Special Type Test Indicators ; Large dial face ,PCN-1LD,Long contact point Model PCN-1LD Graduation 0.01mm Range 1.0mm   The dial plate size of PCN-1A, PCN-1L, and PCN-2BD models has been enlarged, with easy reading due to the lager scale spacing, as a result. Screw type long stems are standard for these large dial face test indicators. Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 1.0 0 - 50 - 0 10 5 4 0.3 42.8

Read more less

Peacock Special Type Test Indicators ; Large dial face ,PCN-1AD Model PCN-1AD Graduation 0.01mm Range 0.5mm   The dial plate size of PCN-1A, PCN-1L, and PCN-2BD models has been enlarged, with easy reading due to the lager scale spacing, as a result. Screw type long stems are standard for these large dial face test indicators. Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.5 0 - 25 - 0 5 5 3 0.3 21.3

Read more less

Peacock Lever Type Dial Indicators PIC TEST ; Change lever type, PC-3L Parallel Model PC-3L Graduation 0.01mm Range 1.0mm   Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning section of the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 1.0 0 - 50 - 0 10 5 4 0.4 43.0

Read more less

Peacock Lever Type Dial Indicators PIC TEST ; Change lever type, PC-3 Parallel Model PC-3 Graduation 0.01mm Range 0.5mm   Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning section of the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.5 0 - 25 - 0 5 5 3 0.4 21.4

Read more less

Peacock Lever Type Dial Indicators PIC TEST ; Change lever type, PC-1L,Long contact point Model PC-1L Graduation 0.01mm Range 1.0mm  Long contact point (L = 43.0mm) Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning section of the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 1.0 0 - 50 - 0 10 5 4 0.4 43.0

Read more less

Peacock NEW PIC TEST ; Without change lever, PCN-6 Vertical The New Pic Test is a lever type dial indicators used in all over the world. It is a measuring instrument used for measurements of restricted areas,and the outside/inside, groove width and centering with the dial gauge installed to the lathe or the milling cutting machine for measurements with the gauges held on the height gauges. Model  PCN-6 Vertical Graduation 0.002mm  Range 0.28mm Without change lever (Automatic inverse type) The lever type dial gauge of this type has no change lever, the contact point inverses automatically in normal or reverse direction as desired and pointer turns always CW to improve the measuring efficiency. Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning sectionof the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) Wide-range forward accuracy Adjacent error Backward error 0.002 0.28 0 -140 - 0 3 2 2 0.3   Dimensions Model L (mm) PCN-6 17.8

Read more less

Peacock NEW PIC TEST ; Without change lever, PCN-S The New Pic Test is a lever type dial indicators used in all over the world. It is a measuring instrument used for measurements of restricted areas,and the outside/inside, groove width and centering with the dial gauge installed to the lathe or the milling cutting machine for measurements with the gauges held on the height gauges. Model PCN-S Graduation 0.001mm  Range 0.14mm Without change lever (Automatic inverse type) The lever type dial gauge of this type has no change lever, the contact point inverses automatically in normal or reverse direction as desired and pointer turns always CW to improve the measuring efficiency. Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning sectionof the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) Wide-range forward accuracy Adjacent error Backward error 0.001 0.14 0 - 70 - 0 3 2 2 0.3   Dimensions Model L (mm) PCN-S 11.7

Read more less

Peacock NEW PIC TEST ; Without change lever, PCN-2 The New Pic Test is a lever type dial indicators used in all over the world. It is a measuring instrument used for measurements of restricted areas,and the outside/inside, groove width and centering with the dial gauge installed to the lathe or the milling cutting machine for measurements with the gauges held on the height gauges. Model PCN-2 Graduation 0.002mm  Range 0.28mm Without change lever (Automatic inverse type) The lever type dial gauge of this type has no change lever, the contact point inverses automatically in normal or reverse direction as desired and pointer turns always CW to improve the measuring efficiency. Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning sectionof the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) Wide-range forward accuracy Adjacent error Backward error 0.002 0.28 0 - 140 - 0 3 2 2 0.3   Dimensions Model L (mm) PCN-2 17.8

Read more less

Peacock NEW PIC TEST ; Without change lever, PCN-1L The New Pic Test is a lever type dial indicators used in all over the world. It is a measuring instrument used for measurements of restricted areas,and the outside/inside, groove width and centering with the dial gauge installed to the lathe or the milling cutting machine for measurements with the gauges held on the height gauges. Model PCN-1L Graduation 0.01mm  Range 1.0mm Without change lever (Automatic inverse type) The lever type dial gauge of this type has no change lever, the contact point inverses automatically in normal or reverse direction as desired and pointer turns always CW to improve the measuring efficiency. Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning sectionof the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) Wide-range forward accuracy Adjacent error Backward error 0.01 1.0 0 - 50 - 0 10 5 4 0.3   Dimensions Model L (mm) PCN-1L 42.8

Read more less

Peacock NEW PIC TEST ; Without change lever, PCN-1B The New Pic Test is a lever type dial indicators used in all over the world. It is a measuring instrument used for measurements of restricted areas,and the outside/inside, groove width and centering with the dial gauge installed to the lathe or the milling cutting machine for measurements with the gauges held on the height gauges. Model PCN-1B Graduation 0.01mm  Range 0.8mm Without change lever (Automatic inverse type) The lever type dial gauge of this type has no change lever, the contact point inverses automatically in normal or reverse direction as desired and pointer turns always CW to improve the measuring efficiency. Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning sectionof the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) Wide-range forward accuracy Adjacent error Backward error 0.01 0.8 0 - 40 - 0 8 5 3 0.3   Dimensions Model L (mm) PCN-1B 22.2

Read more less

Peacock NEW PIC TEST ; Without change lever, PCN-1A The New Pic Test is a lever type dial indicators used in all over the world. It is a measuring instrument used for measurements of restricted areas,and the outside/inside, groove width and centering with the dial gauge installed to the lathe or the milling cutting machine for measurements with the gauges held on the height gauges. Model PCN-1A  Graduation 0.01mm  Range 0.5mm Without change lever (Automatic inverse type) The lever type dial gauge of this type has no change lever, the contact point inverses automatically in normal or reverse direction as desired and pointer turns always CW to improve the measuring efficiency. Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning sectionof the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) Wide-range forward accuracy Adjacent error Backward error 0.01 0.5 0 - 25 - 0 5 5 3 0.3   Dimensions Model L (mm) PCN-1A 21.3

Read more less

Peacock Replaceable Ball contact points (Screw pitch M2.5 P=0.45mm),X-Series     Part No. L (mm) Ball  X-1 9 Steel  X-103 3.5 Steel  X-105 5 Steel  X-107 7.5 Steel  X-112 12.5 Steel  XB-1 9 Carbide

Read more less

Peacock Digital Gauges Integrated Display Type  , PDN-21 Digital Gauges PDN-21 Integrated Display Type Resolution 0.001mm( convertible to 0.01mm )  Range 0 - 20mm Model PDN-21 Range 20mm Resolution Convertible 0.01mm and 0.001mm ( Set 0.001mm at the time of shipment ) Accuracy 0.001mm Display: 0.003mm (excluding quantized error) 0.01mm Display: 0.01mm Measuring force Less than 1.5N Without spring: less than 0.31N Response speed 1000mm/sec Contact point X-2 ( M2.5×0.45 ) Display rotation 280º Operating temperature 0 - 40ºC Functions Convertible 0.01mm and 0.001mm Judgement    OK, ±NG   ( OK=Green ±NG=Red ) Counting direction Conversion Data output RS-232C Power supply (AC Adapter) AC100 - 240V ±10%  50/60Hz Accessories AC Adapter Options for PDN-21 Flat Back No.GB-3D20 Release No.RE-4 Finger Lever No.LL-D20 Lifting Lever No.LL-PD

Read more less

Peacock One Revolution Dial Gauges; 0.001mm, 15DZ, Range 0.16mm,Large dial face ( Ø66.5 ) Model 15DZ  Graduation 0.001mm  Range 0.16mm  Large dial face ( Ø66.5 ) Contact Point ( XB-1 ) Flat back These are high-accuracy dial gauges with the pointer giving less than a full turn that can resist rigorous rigorous continuous measurement. The long stem is made of stainless steel, is high in strenght and is malfunction-freedue to fastening. The dial faces except No. 18 and 17B are easy to read with green and orange (dead zone) Model Graduation  (mm) Range (mm) (Free stroke) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 15DZ 0.001 0.16(3.0) 80-0-80 2.5 ±3 ±4 - - 3 0.7 1.5   Dimensions (mm) Model A B C D E F G H I 15DZ 69.4 41.5 23.7 66.5 15.5 20 4 7.6 49

Read more less

Peacock One Revolution Dial Gauges; 0.001mm, 18, Range 0.16mm,Oil-proof type Model 18  Graduation 0.001mm  Range 0.16mm  Long stem Contact Point ( XB-1 ) Oil-proof type Flat crystal Flat back These are high-accuracy dial gauges with the pointer giving less than a full turn that can resist rigorous rigorous continuous measurement. The long stem is made of stainless steel, is high in strenght and is malfunction-free due to fastening. The dial faces except No. 18 and 17B are easy to read with green and orange (dead zone) Model Graduation  (mm) Range (mm) (Free stroke) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 18 0.001 0.16(3.0) 80-0-80 2.5 ±3 ±4 - - 3 0.5 1.5   Dimensions (mm) Model A B C D E F G H I 18 69.4 41.5 29 55 16.8 20 4 6.5 49

Read more less
