Autonics
Autonics Autonics Fiber optic sensor, Convergent reflective type FLF-320-10
FLF-320-10 Type : Flat type/Flat view Sensing distance : 8mm Min. sensing target : Ø0.0125mm Allowable bend radius : R25 Cable length : 2m Environment_Ambient temperature : -40 to 60℃ Type Flat type/Flat view Sensing distance 8mm Min. sensing target Ø0.0125mm Allowable bend radius R25 Cable length 2m Environment_Ambient temperature -40 to 60℃ Sensing type Convergent reflective type ※The sensing distance is a standard for BF5 Series.※Free cut type's sensing distance can be shortened about max. 20% than the normal according to condition of the cable. [(FC-3) should be used for cutting fiber cable.]
$86.32
Autonics Autonics Fiber optic sensor, Convergent reflective type FLF-320-10A
FLF-320-10A Type : Flat type/Flat view Sensing distance : 100mm Min. sensing target : Ø0.08mm Allowable bend radius : R20 Cable length : 2m Adapter : Adapter Environment_Ambient temperature : -30 to 70℃ Type Flat type/Flat view Sensing distance 100mm Min. sensing target Ø0.08mm Allowable bend radius R20 Cable length 2m Free cut Free cut Adapter Adapter Environment_Ambient temperature -30 to 70℃ Sensing type Convergent reflective type
$95.08
Autonics Autonics Fiber optic sensor, Convergent reflective type FLF-320-10H
FLF-320-10H Type : Flat type/Flat view Sensing distance : 130mm Min. sensing target : Ø0.08mm Allowable bend radius : R25 Cable length : 2m Environment_Ambient temperature : -40 to 105℃ Type Flat type/Flat view Sensing distance 130mm Min. sensing target Ø0.08mm Allowable bend radius R25 Cable length 2m Free cut Free cut Environment_Ambient temperature -40 to 105℃ Sensing type Convergent reflective type
$158.74
Autonics Autonics photoelectric micro sensor, Through-beam type BS3-F1M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.97
Autonics Autonics photoelectric micro sensor ,Through-beam type BS3-F1R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor, Through-beam type BS3-K1M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.97
Autonics Autonics photoelectric micro sensor, Through-beam type BS3-K1R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor, Through-beam type BS3-K1R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor, Through-beam type BS3-L1M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.97
Autonics Autonics photoelectric micro sensor, Through-beam type BS3-L1R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor Through-beam type BS3-L1R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor Through-beam type BS3-R1R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor Through-beam type BS3-R1R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor Through-beam type BS3-U1R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor Through-beam type BS3-U1R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Connection type Ø2.5mm, 4-wire, 1m Core AWG28 (0.08mm), 19-core, insulator out diameter: Ø0.65mm Material Case: PBT, Sensing part: PC
$12.94
Autonics Autonics photoelectric micro sensor Through-beam type BS4-F2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-F2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.19
Autonics Autonics photoelectric micro sensor Through-beam type BS4-F2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-F2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-K2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-K2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.19
Autonics Autonics photoelectric micro sensor Through-beam type BS4-K2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-K2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-L2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-L2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-L2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-L2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.19
Autonics Autonics photoelectric micro sensor Through-beam type BS4-R2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-R2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.19
Autonics Autonics photoelectric micro sensor Through-beam type BS4-R2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-R2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-T2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-T2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-T2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-TA2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-TA2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-TA2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-TA2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-Y2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output NPN open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-Y2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS4-Y2R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥ 0.8 mm × 1.8 mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲,Dark ON: Max. 80㎲ Response frequency 2kHz Light source Infrared LED Peak emission wavelength 940nm Operation mode Light ON/Dark ON(Built-in) Indicator Operation indicator (red LED) Weight ≈ 2.4 g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Current consumption Max. 15mA Control output PNP open collector Load voltage ≤ 24VDC Load current Max. 50mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength 1,000VAC~ 50/60Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$10.10
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F1M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output NPN open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Material Case: PBT, Sensing part: PC
$7.60
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F1M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output PNP open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Material Case: PBT, Sensing part: PC
$7.69
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F1R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output NPN open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Material Case: PBT, Sensing part: PC
$7.60
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F1R-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 50g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output PNP open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Cable type Material Case: PBT, Sensing part: PC
$7.60
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F2M
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 30g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output NPN open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$5.34
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F2M-P
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 30g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output PNP open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$5.34
Autonics Autonics photoelectric micro sensor Through-beam type BS5-F2R
Sensing type Through-beam type Sensing distance 5mm Sensing target Opaque Min. sensing target ≥Ø0.8mm×2mm Hysteresis(distance) ≤0.05mm Response time Light ON: Max. 20㎲, Dark ON: Max. 100㎲ Response frequency 2kHz Light source Infrared LED(940nm) Operation mode Light ON/Dark ON(set by control wire) Indicator Operation indicator (red LED) Weight_Body Approx. 30g Power voltage 5-24VDC ±10%(ripple P-P : max. 10%) Load voltage ≤30VDC Load current Max. 100mA Residual voltage NPN: ≤1.2VDC, PNP: ≤ 1.2VDC Current consumption Max. 30mA Control output NPN open collector output Protection circuit Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit Insulation resistance ≥20 MΩ (250 VDC megger) Noise immunity The square wave noise (pulse width: 1㎲) by the noise simulator ±240VDC Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute Vibration 1.5mm amplitude (max. acceleration 196m/s²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours Shock 15,000 m/s² (approx. 1,500G) in each X, Y, Z direction for 3 times Environment_Ambient illumination Fluorescent lamp: Max. 1,000lx(received illumination) Environment_Ambient temperature -20 to 55℃, storage : -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Protection structure IP50 (IEC standard) Connection Connector type Material Case: PBT, Sensing part: PC
$5.34
